122
-- (Warning indicators
pertaining to the write-protect of the
memory card)*
The write-protect switch is set to lock
position on the memory card.
Access to the memory card was
restricted on another device.
* When [BEEP] is set to [ON] (p. 105), you hear a
melody when the warning indicators appear on
the LCD screen.
If a warning message is displayed, follow
the instructions.
Memory cards
Inconsistencies found in image
database file. Do you want to repair
the image database file?
You cannot record or play back movies
because no movie management
information exists. Select [OK] to
repair.
Inconsistencies found in the image
database file. Back up and recover.
Recover, then import using the
included PC software.
Inconsistencies occur in the image
database file because movie
management information is damaged.
If you select [OK], the management file
is repaired after backing up the movie.
The backed up movies cannot be
recognized.
If you connect to a computer on which
application software is installed, you
can copy the backed up movies to the
computer.
However, the loading of all moves is
not guaranteed.
Buffer overflow. Writing to the media
was not completed in time.
You have performed recording and
erasing operations repeatedly, or a
memory card that has been formatted
by other device is used. Back up the
data to another device (such as a
computer HDD), and then [Empty] the
memory card on the camcorder (p. 83).
The size of the inserted memory card is
not sufficient for copying the movie(s).
Use the recommended memory card
(p. 29).
Recovering data. Please wait.
Your camcorder tries to recover data
automatically if the data writing was
not performed properly.
Cannot recover data.
Writing data onto the media of the
camcorder has failed. Attempts were
made to recover the data, but they were
unsuccessful.
Reinsert the memory card.
Reinsert the memory card a few times.
If even then the indicator flashes, the
memory card could be damaged. Try
with another memory card.
Cannot recognize this
memory card. Format and use again.
Format the memory card using the
camcorder (p. 83). Note that if you
format the memory card, all the
recorded movies and photos are
deleted.
This memory card may not be able to
record or play movies.
Use a memory card recommended for
your camcorder (p. 29).
Description of warning messages
Warning indicators and messages (Continued)
