Sony HXR-NX5R User Manual

47
Recording
Use the following procedure if using a
microphone or external audio device.
1 Select the audio input source.
• Set the INPUT1/INPUT2 (LINE/MIC/
MIC+48V) switch (C or D) based
on the device connected to INPUT1
jack A/INPUT2 jack B.
• To record using a microphone, select
MIC or MIC+48V.
See page 22 for details about
connecting a microphone.
b Notes
• If the switch is set to MIC+48V and you connect
a device that is not compatible with +48V
power, it may damage the connected device.
Check the switch before connecting the device.
• To prevent unwanted noise when no audio
device is connected to the INPUT1 or INPUT2
jack, set the INPUT1/INPUT2 (LINE/MIC/
MIC+48V) switch (C or D) to LINE.
2 Set the CH1 (INT MIC/EXT/MI
SHOE) switch E and CH2 (INT
MIC/EXT/MI SHOE) switch F to
EXT.
• If [INPUT CH SELECT] is set to
[INPUT1/INPUT2] in the [XLR SET]
menu, the audio input on the INPUT1
and INPUT2 jacks are recorded for
CH1 and CH2, respectively.
• If [INPUT CH SELECT] is set to
[INPUT1/INPUT1] in the [XLR SET]
menu, the audio input on the INPUT1
jack is recorded to both CH1 and CH2.
3 Set the input level of the external
audio device.
When the INPUT1/INPUT2 (LINE/
MIC/MIC+48V) switch (C or D) is
set to MIC or MIC+48V, the XLR
microphone input level can be set using
[INPUT1 TRIM]/[INPUT2 TRIM] in
the menu (p. 98). Adjust the setting
based on the sensitivity of the
microphone.
z Tip
• Use the following procedure if using a stereo
microphone fitted with two XLR plugs.
AConnect the INPUT1 jack A to the L (left)
channel, and the INPUT2 jack B to the R
(right) channel.
BSet the CH1 (INT MIC/EXT/MI SHOE)
switch E and CH2 (INT MIC/EXT/MI
SHOE) switch F to EXT.
CPress the MENU button, and set (AUDIO
SET) t [XLR SET] t [INPUT CH
SELECT] to [INPUT1/INPUT2].
You can record audio with a Multi-
Interface Shoe-compatible microphone.
Recording sound from an
external audio device
Connected device Switch position
External audio device (such
as mixer)
LINE
Dynamic microphone or
microphone with built-in
battery
MIC
+48V powered (phantom
power) microphone
MIC+48V
[XLR SET] >
[INPUT CH
SELECT] setting
Sound recorded to CH1 and
CH2
INPUT1/
INPUT2
INPUT1
INPUT2
CH1
CH2
INPUT1/
INPUT1
INPUT1
CH1
CH2
Recording sound from a Multi
Interface Shoe compatible
microphone (sold separately)
Continued ,

Sony HXR-NX5R Specifications

General

Camcorder type	Handheld camcorder
Minimum illumination	1 lx
Supported aspect ratios	4:3, 16:9
Product color	Black
DC-in jack	Yes
PictBridge	No
Composite video out	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	7.2 h
Battery technology	-
Video resolutions	720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	50 Mbit/s
Sensor type	CMOS
Total megapixels	2.07 MP
Optical sensor size	1/2.8 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	MS PRO Duo, SD, SDHC, SDXC
Maximum memory card size	64 GB
Internal storage capacity	- GB
Audio system	Dolby Digital
PCM digital audio	16-bit/48 kHz
Audio formats supported	PCM
Filter size	72 mm
Digital zoom	40 x
Optical zoom	20 x
Focal length range	4.1 - 82 mm
Maximum aperture number	3.4
Minimum aperture number	1.6
Focal length (35mm film equivalent)	28.8 - 576 mm
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/3 - 1/10000 s
Viewfinder type	Electronic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables included	AC, USB
Maximum image resolution	- pixels
Display diagonal	8.8 \

Weight and Dimensions

Depth	385 mm
Width	176 mm
Height	199.5 mm
Weight	2110 g
