35
Recording
Adjusting the focus
You can adjust the focus manually for
different recording conditions.
1 During recording or standby, set
the FOCUS switch B to MAN.
9 appears.
2 Turn the focus ring A to adjust
the focus.
9 changes to when the focus
cannot be adjusted any farther, and
changes to when the focus cannot be
adjusted any closer.
To adjust automatically
Set the FOCUS switch B to AUTO.
9 disappears and the automatic focus
adjustment is restored.
z Tips
• The focal length information (the distance at
which the subject is in focus; for when it is dark
and hard to adjust the focus) appears for about 3
seconds in the following cases.
– When you set the FOCUS switch B to MAN
and 9 appears.
– When you rotate the focus ring A while 9
is displayed.
• You can switch the focal length information
between meters and feet ([FOCUS DISPLAY],
p. 101).
Using push auto focus
Set the FOCUS switch B to MAN, then
press and hold the PUSH AUTO/FOCUS
HOLD button C while shooting. The
image is shot with automatic focus. Keep
the button pressed to shoot. If you release
the button, the setting returns to manual
focusing.
Using focus hold
Set the FOCUS switch B to AUTO, then
press and hold the PUSH AUTO/FOCUS
HOLD button C while shooting. The
image is shot with the focus fixed at the
point you start to press the button. Keep the
button pressed to shoot. If you release the
button, the setting returns to auto focusing.
The selected area on the LCD screen is
magnified and displayed. This is useful
when adjusting the focus.
[FOCUS MAGNIFIER] is assigned to the
ASSIGN6/FOCUS MAG button (p. 54).
Press the ASSIGN6/FOCUS MAG
button.
The center of the screen is magnified.
The setting changes with each press of the
button.
Using automatic focus/fixed
focus temporarily (Push auto
focus/Focus hold)
Focusing using the focus
magnifier
Continued ,

Sony HXR-NX5R Specifications

General

Camcorder type	Handheld camcorder
Minimum illumination	1 lx
Supported aspect ratios	4:3, 16:9
Product color	Black
DC-in jack	Yes
PictBridge	No
Composite video out	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	7.2 h
Battery technology	-
Video resolutions	720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	50 Mbit/s
Sensor type	CMOS
Total megapixels	2.07 MP
Optical sensor size	1/2.8 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	MS PRO Duo, SD, SDHC, SDXC
Maximum memory card size	64 GB
Internal storage capacity	- GB
Audio system	Dolby Digital
PCM digital audio	16-bit/48 kHz
Audio formats supported	PCM
Filter size	72 mm
Digital zoom	40 x
Optical zoom	20 x
Focal length range	4.1 - 82 mm
Maximum aperture number	3.4
Minimum aperture number	1.6
Focal length (35mm film equivalent)	28.8 - 576 mm
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/3 - 1/10000 s
Viewfinder type	Electronic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables included	AC, USB
Maximum image resolution	- pixels
Display diagonal	8.8 \

Weight and Dimensions

Depth	385 mm
Width	176 mm
Height	199.5 mm
Weight	2110 g
