Sony HXR-NX5R User Manual

79
Using Network Functions
You can also continue transferring
files.
b Notes
• Only files that were recorded by the camcorder
can be transferred using FTP.
• Do not exchange a memory card after starting a
file transfer.
• FTP transfer is not available in shooting mode.
To start a file transfer, first press the
THUMBNAIL button to switch to playback
mode.
• Only wired LAN connection is supported when
[AIRPLANE MODE] is set to [ON].
You can check whether all files have been
transferred. If the camcorder is configured
to turn off automatically after transfer is
completed, it is recommended that you
check the transfer results.
1 Press the MENU button.
2 Select (NETWORK SET) t
[FTP TRANSFER] t [FTP
RESULT].
• The transfer results are displayed.
• The displayed transfer results contains
the following items.
Date
Date and time of transfer start
Number of Contents
Number of transferred contents / total
number of transfer contents
Result
Transfer result
Checking FTP transfer results
Importing a root
certificate
If [Secure Protocol] is set to [ON] for FTP
transfer or USTREAM streaming, a root
certificate is required. The camcorder
contains a built-in root certificate, which
can also be updated. To update the root
certificate, save the certificate on a memory
card and then import the certificate from the
memory card.
1 Write the root certificate to a
memory card.
Write the certificate in PEM format with
a “certification.pem” file name to the
root directory of the memory card.
2 Insert the memory card with the
root certificate into memory card
slot A of the camcorder.
3 Press the MENU button.
4 Select (NETWORK SET) t
[ROOT CERTIFICATE] t [OK].
• The root certificate starts importing.
• The certificate is imported
successfully when “Completed.”
appears. Select to dismiss the
screen.
b Notes
• Do not eject the memory card while a certificate
is being imported.
• Resetting network settings (p. 80) will delete the
root certificate imported from the memory card,
and will initialize the root certificate of the
camcorder.
Continued ,

Sony HXR-NX5R Specifications

General

Camcorder type	Handheld camcorder
Minimum illumination	1 lx
Supported aspect ratios	4:3, 16:9
Product color	Black
DC-in jack	Yes
PictBridge	No
Composite video out	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	7.2 h
Battery technology	-
Video resolutions	720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	50 Mbit/s
Sensor type	CMOS
Total megapixels	2.07 MP
Optical sensor size	1/2.8 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	MS PRO Duo, SD, SDHC, SDXC
Maximum memory card size	64 GB
Internal storage capacity	- GB
Audio system	Dolby Digital
PCM digital audio	16-bit/48 kHz
Audio formats supported	PCM
Filter size	72 mm
Digital zoom	40 x
Optical zoom	20 x
Focal length range	4.1 - 82 mm
Maximum aperture number	3.4
Minimum aperture number	1.6
Focal length (35mm film equivalent)	28.8 - 576 mm
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/3 - 1/10000 s
Viewfinder type	Electronic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables included	AC, USB
Maximum image resolution	- pixels
Display diagonal	8.8 \

Weight and Dimensions

Depth	385 mm
Width	176 mm
Height	199.5 mm
Weight	2110 g
