Page #133 background imageLoading...
Page #133 background image
133
Additional Information
Maintenance and precautions
Recording and playback on your
camcorder
Your camcorder can record with HD (high
definition) high image quality, based on the
XAVC S format.
This uses a Long-GOP video compression
format for recording.
Video*: MPEG-4AVC/H.264
60i model:
1920×1080/60p, 1920×1080/30p,
1920×1080/24p
50i model:
1920×1080/50p, 1920×1080/25p
Audio: LPCM 2-ch
Recording media: Memory card
* The camcorder is not able to play back data that
is recorded in XAVC S format using settings
other than those described above.
Recording and playback on the
camcorder
Based on the AVCHD format, your
camcorder records with the HD (high
definition) image quality.
Video*: MPEG-4AVC/H.264
60i model:
1920×1080/60p, 1920×1080/60i,
1920×1080/30p, 1920×1080/24p,
1440×1080/60i, 1280×720/60p
50i model:
1920×1080/50p, 1920×1080/50i,
1920×1080/25p, 1440×1080/50i,
1280×720/50p
Audio: Dolby Digital 2-ch, LPCM 2-ch
Recording media: memory card (sold
separately)
* Data recorded in AVCHD format other than the
above mentioned cannot be played back on your
camcorder.
Because the AVCHD format uses a data
compression system, images may be distorted in
scenes where the image, angle, or brightness
changes drastically. This is not a malfunction.
A memory card formatted on a computer does
not have guaranteed compatibility with your
camcorder.
Data read/write speed may vary depending on
the combination of the memory card and
memory card compliant product you use.
Damaged or lost image data will not be
compensated for, and may occur in the
following cases:
If you eject the memory card, turn the power
off on your camcorder, or remove the battery
pack for replacement while your camcorder is
reading or writing image files on the memory
card (while the access lamp is lit or flashing).
If you use the memory card near electric
fields, magnetic fields, or other sources of
electromagnetic noise.
It is recommended to make a back-up of
important data on the hard disk of a computer.
Do not attach a label or the like on memory
card.
Do not touch, or allow metallic objects to come
into contact with the terminals.
Do not bend, drop or apply strong force to the
memory card.
Do not disassemble or modify the memory card.
Do not let the memory card get wet.
Be careful to keep memory card out of the reach
of small children. There is danger that a child
might swallow it.
Do not insert anything other than the compliant
size of memory card into the memory card slot.
Doing so may cause a malfunction.
Do not use or keep the memory card in the
following locations:
Places subject to extremely high temperature,
such as a car parked outside in the summer
Places under direct sunlight
Places with extremely high humidity or
subject to corrosive gases
About the XAVC S format
About the AVCHD format
About memory cards
Continued ,

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony HXR-NX5R and is the answer not in the manual?

Sony HXR-NX5R Specifications

General IconGeneral
Camcorder typeHandheld camcorder
Minimum illumination1 lx
Supported aspect ratios4:3, 16:9
Product colorBlack
DC-in jackYes
PictBridgeNo
Composite video out1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out0
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Battery voltage7.2 V
Battery capacity- mAh
Battery life (max)7.2 h
Battery technology-
Video resolutions720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate50 fps
Video formats supportedAVC, AVCHD, H.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Bitrate at maximum video resolution50 Mbit/s
Sensor typeCMOS
Total megapixels2.07 MP
Optical sensor size1/2.8 \
Memory slots2
Camcorder media typeMemory card
Compatible memory cardsMS PRO Duo, SD, SDHC, SDXC
Maximum memory card size64 GB
Internal storage capacity- GB
Audio systemDolby Digital
PCM digital audio16-bit/48 kHz
Audio formats supportedPCM
Filter size72 mm
Digital zoom40 x
Optical zoom20 x
Focal length range4.1 - 82 mm
Maximum aperture number3.4
Minimum aperture number1.6
Focal length (35mm film equivalent)28.8 - 576 mm
Focus adjustmentAuto/Manual
Closest focusing distance0.01 m
Camera shutter speed1/3 - 1/10000 s
Viewfinder typeElectronic
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables includedAC, USB
Maximum image resolution- pixels
Display diagonal8.8 \
Weight and Dimensions IconWeight and Dimensions
Depth385 mm
Width176 mm
Height199.5 mm
Weight2110 g
