31
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000/32S3000/40S3000/46S3000
KDL-26S3000 ONLY
Wire Dress Speaker Cables as shown.
BOTH R/L cables are dressed in FGC-3
conductive clip.
Right Speaker wires and H4-Bd cables are
dressed UNDER AC Inlet.
Torque: 6kg.cm (+-1.0kg.cm)
OPERATION PROCESS
TORQUE SPECIFICATION
1
2
Right Speaker Wires and H4 Cables are dressed UNDER AC INLET.
RIGHT SPEAKER Cables
SPEAKER HARNESS
To Next Page
