Sony KV-13FM13 - Page 41

— 41 —
KV-13FM13 / 13FM14
NOTE: The components identiÞ ed by shading
and
!
mark are critical for safety. Replace only
with part number speciÞ ed.
NOTE: Les composants identiÞ es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero speciÞ e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
D627 8-719-110-03 DIODE MTZJ-T-77-7.5A
D628 8-719-510-48 DIODE D1N20R-TA
FUSE
! F601 1-576-193-11 FUSE 6.3A/125V
FERRITE BEAD
FB501 1-410-397-21 FERRITE 1.1µH
FB502 1-410-397-21 FERRITE 1.1µH
FB503 1-410-397-21 FERRITE 1.1µH
FB600 1-412-911-11 FERRITE 0µH
FB601 1-412-911-11 FERRITE 0µH
FB602 1-412-911-11 FERRITE 0µH
FB603 1-412-911-11 FERRITE 0µH
FB604 1-412-911-11 FERRITE 0µH
FB605 1-412-911-11 FERRITE 0µH
FB606 1-412-911-11 FERRITE 0µH
FB609 1-412-911-11 FERRITE 0µH
FB610 1-412-911-11 FERRITE 0µH
IC
IC401 8-759-490-17 IC TDA7057AQ/N2
IC405 8-759-450-93 IC NJM2521M-TE1
! IC501 8-759-700-07 IC NJM2903M-TE2
IC502 8-759-980-58 IC TDA8172
! IC601 8-749-018-45 IC STR-F6424
! IC602 8-749-016-47 IC EA135-F12
IC603 8-759-653-07 IC PQ09RD21
IC604 8-759-714-26 IC LM7805CT
JACK
J201 1-794-115-11 JACK BLOCK, PIN 2P
CHIP CONDUCTOR
JR001 1-216-295-11 SHORT
JR002 1-216-295-11 SHORT
JR403 1-216-295-11 SHORT
JR501 1-216-295-11 SHORT
JR502 1-216-295-11 SHORT
JR503 1-216-295-11 SHORT
JR505 1-216-295-11 SHORT
JR520 1-216-295-11 SHORT
JR521 1-216-295-11 SHORT
JR524 1-216-295-11 SHORT
JR525 1-216-295-11 SHORT
JR528 1-216-295-11 SHORT
JR529 1-216-295-11 SHORT
JR2001 1-216-295-11 SHORT
JR2003 1-216-295-11 SHORT
COIL
L101 1-412-029-11 INDUCTOR 10µH
L102 1-412-032-11 INDUCTOR 100µH
L103 1-412-029-11 INDUCTOR 10µH
! L501 1-409-955-11 INDUCTOR 8MH
L502 1-412-552-11 INDUCTOR 2.2MH
L503 1-406-677-11 INDUCTOR 10MH
L504 1-412-533-21 INDUCTOR 47µH
L508 1-406-982-41 INDUCTOR 680µH
! L509 1-419-488-11 COIL, HORIZONTAL LINEARITY
L510 1-412-528-11 INDUCTOR 18µH
L603 1-412-529-11 INDUCTOR 22µH
L604 1-412-525-31 INDUCTOR 10µH
L605 1-412-529-11 INDUCTOR 22µH
PHOTO COUPLER
! PH601 8-749-010-64 PHOTO COUPLER PC123FY2
IC LINK
! PS401 1-576-413-21 LINK, IC
TRANSISTOR
Q101 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q411 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q501 8-729-140-50 TRANSISTOR 2SC3209LK-TP
! Q502 8-729-051-69 TRANSISTOR 2SD2624
! Q503 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q504 8-729-053-87 TRANSISTOR KTC4370A
! Q505 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
! Q506 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
! Q507 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q604 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
! Q605 8-729-046-40 TRANSISTOR 2SK2663
Q606 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q607 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q608 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q609 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R101 1-216-073-00 RES-CHIP 10K 5% 1/10W
R103 1-216-295-11 SHORT
R105 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R107 1-216-025-11 RES-CHIP 100 5% 1/10W
R108 1-216-025-11 RES-CHIP 100 5% 1/10W
A
