KV-13FM13 / 13FM14
REF.NO. PART NO. DESCRIPTION VALUES
REF.NO. PART NO. DESCRIPTION VALUES
COIL
L701 1-408-613-31 INDUCTOR 68µH
TRANSISTOR
Q700 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q701 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R700 1-249-433-11 CARBON 22K 5% 1/4W
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-409-11 CARBON 220 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-249-421-11 CARBON 2.2K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-381-11 CARBON 1 5% 1/4W
R707 1-249-383-11 CARBON 1.5 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-260-328-11 CARBON 1K 5% 1/2W
R712 1-260-328-11 CARBON 1K 5% 1/2W
R713 1-260-328-11 CARBON 1K 5% 1/2W
R714 1-260-087-11 CARBON 100 5% 1/2W
R715 1-260-132-11 CARBON 560K 5% 1/2W
R716 1-260-123-11 CARBON 100K 5% 1/2W
R717 1-216-373-11 METAL OXIDE 2.2 5% 2W
R719 1-215-884-11 METAL OXIDE 47 5% 2W
R720 1-249-421-11 CARBON 2.2K 5% 1/4W
R721 1-249-421-11 CARBON 2.2K 5% 1/4W
VARIABLE RESISTOR
RV701 1-241-656-11 RES, ADJ, METAL FILM 110M
HC
* A-1372-814-A HC (VAR) BOARD, MOUNTED
CONNECTOR
* CN2201 1-564-522-11 PLUG,CONNECTOR 7P
DIODE
D2201 8-719-057-09 DIODE LNJ801LPDJA
IC
IC2201 8-742-211-20 HYB IC SBX3071-71
RESISTOR
R2201 1-249-415-11 CARBON 680 5% 1/4W
R2202 1-249-416-11 CARBON 820 5% 1/4W
R2203 1-249-421-11 CARBON 2.2K 5% 1/4W
R2204 1-249-427-11 CARBON 6.8K 5% 1/4W
R2205 1-249-417-11 CARBON 1K 5% 1/4W
R2207 1-247-807-31 CARBON 100 5% 1/4W
SWITCH
S2201 1-762-196-21 SWITCH, TACTILE
S2202 1-762-196-21 SWITCH, TACTILE
S2203 1-762-196-21 SWITCH, TACTILE
S2204 1-762-196-21 SWITCH, TACTILE
S2205 1-762-196-21 SWITCH, TACTILE
S2206 1-762-196-21 SWITCH, TACTILE
HD
* A-1372-816-A HD (COM) BOARD, MOUNTED
CAPACITOR
C2211 1-126-960-11 ELECT 1µF 20% 50V
C2212 1-126-940-11 ELECT 330µF 20% 25V
C2222 1-104-664-11 ELECT 47µF 20% 25V
CONNECTOR
* CN2210 1-564-523-11 PLUG,CONNECTOR 8P
* CN2211 1-564-518-11 PLUG,CONNECTOR 3P
* CN2212 1-564-518-11 PLUG,CONNECTOR 3P
* CN2213 1-564-522-11 PLUG,CONNECTOR 7P
DIODE
D2211 8-719-108-12 DIODE RD9.1EW-T1
D2212 8-719-110-17 DIODE MTZJ-T-77-10B
D2213 8-719-924-13 DIODE MTZJ-T-77-22B
JACK
J2211 1-794-266-21 JACK, PIN 2P
J2212 1-568-267-21 JACK
RESISTOR
R2211 1-249-419-11 CARBON 1.5K 5% 1/4W
R2212 1-249-421-11 CARBON 2.2K 5% 1/4W
R2213 1-249-427-11 CARBON 6.8K 5% 1/4W
R2215 1-247-895-91 CARBON 470K 5% 1/4W
R2216 1-249-425-11 CARBON 4.7K 5% 1/4W
R2217 1-249-409-11 CARBON 220 5% 1/4W
R2219 1-249-425-11 CARBON 4.7K 5% 1/4W
