MXD-D40
20
3
two claws
4
loading panel
2
1
3-2. LOADING PANEL
3-3. CASE
Note: Follow the disassembly procedure in the numerical order given.
1
two screws
(case3 TP2)
1
two screws
(case3 TP2)
1
two screws
(case3 TP2)
2
case
