MXD-D40
23
3-8. HOLDER ASSY
3-9. LOADING MOTOR ASSY (M103)
3
5
6
holder assy
4
boss
1
tension spring (holder)
4
boss
2
claw
2
two screws
(PWH1.7
×
2.5)
1
belt (loading)
3
loading motor assy
(M103)
