44
MXD-D40
Adjustment and checking Loacation:
D101
CN101
IC101
CN105
IC151
IC190
1
7
1. I+3V
2. IOP
3. GND
4. TE
5. FE
6. VC
7. RF
– BD (MD) BOARD (Side A) –
– BD (MD) BOARD (Side B) –
Note: It is useful to use the jig for checking the waveform. (Refer to Ser-
vicing Notes on page 9)
