MXD-D40
5757
1.7 Vp-p
468 ns
3.1 Vp-p
62.5 ns
2.8 Vp-p
100 ns
1.0 ± 0.2 Vp-p
• Waveforms
– BD (CD) Board –
1 IC101 wg (MDP) (CD PLAY mode)
2 IC101 el (FE) (CD PLAY mode)
3 IC101 ra (TE) (CD PLAY mode)
6 IC101 us (XTAO)
5 IC101 t; (RFAC) (CD PLAY mode)
4 IC101 rd (RFDC) (CD PLAY mode)
– BD (MD) Board –
1 IC101 1 (I), 2 (J) (MD PLAY mode)
3 IC101 8 (E), 9 (F) (MD PLAY mode)
4 IC151 qh (OSCI)
2 IC101 4 (A) (MD PLAY mode)
5 IC151 o; (FS4)
2.6 Vp-p
7.9 µs
200 mVp-p
180 mVp-p
1.3 Vp-p
3.1 Vp-p
29 ns
0.5 Vp-p
0.1 Vp-p
0.06 Vp-p
3.1 Vp-p
22 ns
3.2 Vp-p
56.6 µs
– MAIN Board –
1 IC801 qd (XOUT)
2 IC800 qd (X-OUT)
– DISPLAY Board –
1 IC751 yg (OSCI)
