Sony MXD-D40 - Page 90

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
90
MXD-D40
BD (MD) DISPLAY
S105 1-771-955-21 SWITCH, PUSH (1 KEY) (REC POSITION)
< VIBRATOR >
X171 1-781-569-21 OSCILLATOR, CRYSTAL (90.3168MHz)
**************************************************************
A-4725-634-A DISPLAY BOARD, COMPLETE (AEP, UK)
A-4725-641-A DISPLAY BOARD, COMPLETE (US, Canadian)
A-4725-648-A DISPLAY BOARD, COMPLETE (Singapore)
************************************
3-362-478-01 HOLDER (T), LED
* 4-955-901-01 CUSHION (FL)
* 4-996-686-03 HOLDER (FL)
< CAPACITOR >
C751 1-162-290-31 CERAMIC 470PF 10% 50V
C752 1-162-290-31 CERAMIC 470PF 10% 50V
C753 1-164-159-11 CERAMIC 0.1uF 50V
C754 1-126-795-11 ELECT 10uF 20% 50V
C755 1-164-159-11 CERAMIC 0.1uF 50V
C756 1-162-290-31 CERAMIC 470PF 10% 50V
C757 1-162-290-31 CERAMIC 470PF 10% 50V
C758 1-162-290-31 CERAMIC 470PF 10% 50V
C759 1-162-306-11 CERAMIC 0.01uF 30% 16V
C760 1-162-215-31 CERAMIC 47PF 5% 50V
C761 1-126-795-11 ELECT 10uF 20% 50V
C762 1-126-795-11 ELECT 10uF 20% 50V
C792 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-779-555-21 CONNECTOR, FFC (LIF (NON-ZIF)) 18P
* CN702 1-691-670-11 CONNECTOR, BOARD TO BOARD 5P
< DIODE >
D751 8-719-046-44 LED SEL5221S (NORMAL CD SYNCHRO)
D752 8-719-046-44 LED SEL5221S (HIGH CD SYNCHRO)
< CONNECTOR >
* EPT792 1-690-880-31 LEAD (WITH CONNECTOR)
< FILTER >
FL751 1-517-998-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC751 8-759-680-17 IC MSM9201-04GS-K
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR DTC114ES
Q752 8-729-900-80 TRANSISTOR DTC114ES
Q753 8-729-620-05 TRANSISTOR 2SC2603-EF
Q754 8-729-620-05 TRANSISTOR 2SC2603-EF
Q791 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-413-11 CARBON 470 5% 1/4W
R703 1-249-415-11 CARBON 680 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W
R705 1-249-419-11 CARBON 1.5K 5% 1/4W
R706 1-249-421-11 CARBON 2.2K 5% 1/4W
R707 1-249-425-11 CARBON 4.7K 5% 1/4W
R721 1-249-411-11 CARBON 330 5% 1/4W
R722 1-249-413-11 CARBON 470 5% 1/4W
R723 1-249-415-11 CARBON 680 5% 1/4W
R724 1-249-417-11 CARBON 1K 5% 1/4W
R725 1-249-419-11 CARBON 1.5K 5% 1/4W
R726 1-249-421-11 CARBON 2.2K 5% 1/4W
R727 1-249-425-11 CARBON 4.7K 5% 1/4W
R728 1-249-429-11 CARBON 10K 5% 1/4W
R731 1-249-411-11 CARBON 330 5% 1/4W
R732 1-249-413-11 CARBON 470 5% 1/4W
R733 1-249-415-11 CARBON 680 5% 1/4W
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-419-11 CARBON 1.5K 5% 1/4W
R741 1-249-411-11 CARBON 330 5% 1/4W
R742 1-249-413-11 CARBON 470 5% 1/4W
R743 1-249-415-11 CARBON 680 5% 1/4W
R744 1-249-417-11 CARBON 1K 5% 1/4W
R745 1-249-419-11 CARBON 1.5K 5% 1/4W
R746 1-249-421-11 CARBON 2.2K 5% 1/4W
R751 1-249-409-11 CARBON 220 5% 1/4W
R752 1-249-409-11 CARBON 220 5% 1/4W
R753 1-247-807-31 CARBON 100 5% 1/4W
R754 1-247-807-31 CARBON 100 5% 1/4W
R755 1-249-441-11 CARBON 100K 5% 1/4W
R756 1-249-441-11 CARBON 100K 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
R758 1-247-807-31 CARBON 100 5% 1/4W
R759 1-247-807-31 CARBON 100 5% 1/4W
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-247-843-11 CARBON 3.3K 5% 1/4W
R762 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S701 1-475-543-11 ENCODER, ROTARY
(l AMS L ENTER (CD))
S702 1-762-875-21 SWITCH, KEYBOARD (x (CD))
S703 1-762-875-21 SWITCH, KEYBOARD (X (CD))
S704 1-762-875-21 SWITCH, KEYBOARD (H (CD))
S705 1-762-875-21 SWITCH, KEYBOARD (REC-IT)
S706 1-762-875-21 SWITCH, KEYBOARD (M (CD))
S707 1-762-875-21 SWITCH, KEYBOARD (m (CD))
S721 1-475-543-11 ENCODER, ROTARY
(l AMS L PUSH ENTER (MD))
S722 1-762-875-21 SWITCH, KEYBOARD (CLEAR (MD))
S723 1-762-875-21 SWITCH, KEYBOARD (TIME/CHAR MD)
S724 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE MD)
S725 1-762-875-21 SWITCH, KEYBOARD (INPUT)
S726 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S727 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE CD)
S728 1-762-875-21 SWITCH, KEYBOARD (TIME CD)
S729 1-762-875-21 SWITCH, KEYBOARD (CLEAR (CD))
S731 1-762-875-21 SWITCH, KEYBOARD (m (MD))
S732 1-762-875-21 SWITCH, KEYBOARD (YES)
S733 1-762-875-21 SWITCH, KEYBOARD (MENU/NO)
