A Image sensor position mark (61)
B Battery cover
C Memory card cover
D Tripod receptacle
• Use a tripod with a screw length of less than
5.5 mm (7/32 inch). You will be unable to
firmly secure the camera to tripods having
screws longer than 5.5 mm (7/32 inch), and
may damage the camera.
E Battery compartment
F Connection plate cover
Use this when using an AC-PW20 AC
Adaptor (sold separately). Insert the
connection plate into the battery
compartment, then pass the cord through the
connection plate cover as shown below.
• Make sure that the cord is not pinched when
you close the battery cover.
G Access lamp
H Memory card insertion slot
A Screw
B Flash*
C Connector*
* Do not touch this part directly.
If it is dirty, wipe it off with a soft clean cloth.
Flash
