– 81 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CD
< JUMPER RESISTOR >
JR701 1-216-296-00 SHORT 0
JR702 1-216-296-00 SHORT 0
JR703 1-216-296-00 SHORT 0
JR704 1-216-296-00 SHORT 0
JR705 1-216-296-00 SHORT 0
JR706 1-216-296-00 SHORT 0
JR707 1-216-296-00 SHORT 0
JR708 1-216-295-00 SHORT 0
JR709 1-216-296-00 SHORT 0
JR710 1-216-296-00 SHORT 0
JR711 1-216-296-00 SHORT 0
JR712 1-216-296-00 SHORT 0
JR713 1-216-296-00 SHORT 0
JR714 1-216-296-00 SHORT 0
JR715 1-216-296-00 SHORT 0
JR716 1-216-296-00 SHORT 0
JR717 1-216-296-00 SHORT 0
JR718 1-216-296-00 SHORT 0
JR719 1-216-296-00 SHORT 0
JR720 1-216-296-00 SHORT 0
JR721 1-216-296-00 SHORT 0
JR722 1-216-296-00 SHORT 0
JR723 1-216-296-00 SHORT 0
JR724 1-216-296-00 SHORT 0
JR725 1-216-296-00 SHORT 0
JR726 1-216-296-00 SHORT 0
JR727 1-216-295-00 SHORT 0
JR728 1-216-296-00 SHORT 0
JR729 1-216-296-00 SHORT 0
JR730 1-216-296-00 SHORT 0
JR731 1-216-296-00 SHORT 0
JR732 1-216-296-00 SHORT 0
JR733 1-216-296-00 SHORT 0
JR734 1-216-296-00 SHORT 0
JR735 1-216-296-00 SHORT 0
JR736 1-216-296-00 SHORT 0
JR737 1-216-296-00 SHORT 0
JR738 1-216-296-00 SHORT 0
JR739 1-216-296-00 SHORT 0
JR740 1-216-296-00 SHORT 0
JR741 1-216-296-00 SHORT 0
JR742 1-216-296-00 SHORT 0
JR743 1-216-296-00 SHORT 0
JR744 1-216-296-00 SHORT 0
JR745 1-216-296-00 SHORT 0
JR746 1-216-296-00 SHORT 0
JR747 1-216-296-00 SHORT 0
JR748 1-216-296-00 SHORT 0
JR749 1-216-296-00 SHORT 0
JR750 1-216-296-00 SHORT 0
JR751 1-216-296-00 SHORT 0
JR752 1-216-296-00 SHORT 0
JR753 1-216-295-00 SHORT 0
JR754 1-216-295-00 SHORT 0
JR755 1-216-296-00 SHORT 0
JR756 1-216-296-00 SHORT 0
JR757 1-216-296-00 SHORT 0
JR758 1-216-296-00 SHORT 0
JR759 1-216-296-00 SHORT 0
JR760 1-216-296-00 SHORT 0
JR761 1-216-296-00 SHORT 0
JR762 1-216-296-00 SHORT 0
JR763 1-216-296-00 SHORT 0
JR764 1-216-296-00 SHORT 0
JR765 1-216-296-00 SHORT 0
JR766 1-216-296-00 SHORT 0
JR767 1-216-296-00 SHORT 0
JR768 1-216-296-00 SHORT 0
JR769 1-216-296-00 SHORT 0
JR770 1-216-296-00 SHORT 0
JR771 1-216-296-00 SHORT 0
JR772 1-216-296-00 SHORT 0
JR773 1-216-296-00 SHORT 0
JR774 1-216-296-00 SHORT 0
JR775 1-216-296-00 SHORT 0
JR776 1-216-296-00 SHORT 0
JR777 1-216-296-00 SHORT 0
JR778 1-216-296-00 SHORT 0
JR779 1-216-296-00 SHORT 0
JR780 1-216-296-00 SHORT 0
JR781 1-216-295-00 SHORT 0
JR782 1-216-296-00 SHORT 0
JR783 1-216-296-00 SHORT 0
JR784 1-216-296-00 SHORT 0
JR785 1-216-295-00 SHORT 0
JR786 1-216-295-00 SHORT 0
JR787 1-216-295-00 SHORT 0
< COIL >
L701 1-410-188-51 CHIP, INDUCTOR 0.47uH
L702 1-414-137-31 INDUCTOR, MICRO 0.22uH
< TRANSISTOR >
Q701 8-729-903-46 TRANSISTOR 2SB1132-P
< RESISTOR >
R701 1-216-260-11 RES-CHIP 390K 5% 1/8W
R702 1-216-073-00 METAL CHIP 10K 5% 1/10W
R703 1-216-222-00 RES-CHIP 10K 5% 1/8W
R704 1-216-073-00 METAL CHIP 10K 5% 1/10W
R705 1-216-222-00 RES-CHIP 10K 5% 1/8W
R706 1-216-260-11 RES-CHIP 390K 5% 1/8W
R707 1-216-001-00 METAL CHIP 10 5% 1/10W
