– 92 –
Q9 8-729-930-99 TRANSISTOR 2SC2413KP
< RESISTOR >
R1 1-216-029-11 METAL CHIP 150 5% 1/10W
R2 1-216-158-00 RES-CHIP 22 5% 1/8W
R3 1-216-017-11 RES-CHIP 47 5% 1/8W
R4 1-216-089-11 RES-CHIP 47K 5% 1/10W
R5 1-216-035-00 METAL CHIP 270 5% 1/10W
R6 1-216-037-00 METAL CHIP 330 5% 1/10W
R7 1-216-025-11 RES-CHIP 100 5% 1/10W
R8 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R9 1-216-166-00 RES-CHIP 47 5% 1/8W
R10 1-216-220-00 RES-CHIP 8.2K 5% 1/8W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-081-00 METAL CHIP 22K 5% 1/10W
R13 1-216-093-11 RES-CHIP 68K 5% 1/10W
R14 1-216-049-11 RES-CHIP 1K 5% 1/10W
R15 1-216-105-11 RES-CHIP 220K 5% 1/10W
R16 1-216-041-00 METAL CHIP 470 5% 1/10W
R17 1-216-073-00 METAL CHIP 10K 5% 1/10W
R18 1-216-025-11 RES-CHIP 100 5% 1/10W
R19 1-216-041-00 METAL CHIP 470 5% 1/10W
R20 1-216-081-00 METAL CHIP 22K 5% 1/10W
R21 1-216-033-00 METAL CHIP 220 5% 1/10W
R22 1-216-049-11 RES-CHIP 1K 5% 1/10W
R23 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R24 1-216-073-00 METAL CHIP 10K 5% 1/10W
R25 1-216-049-11 RES-CHIP 1K 5% 1/10W
R26 1-216-254-00 RES-CHIP 220K 5% 1/8W
R27 1-216-073-00 METAL CHIP 10K 5% 1/10W
R28 1-216-073-00 METAL CHIP 10K 5% 1/10W
R29 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R30 1-216-037-00 METAL CHIP 330 5% 1/10W
R31 1-216-037-00 METAL CHIP 330 5% 1/10W
R40 1-216-081-00 METAL CHIP 22K 5% 1/10W
R41 1-216-194-00 METAL CHIP 680 5% 1/8W
R42 1-216-192-00 METAL CHIP 560 5% 1/8W
R43 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R44 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R45 1-216-033-00 METAL CHIP 220 5% 1/10W
R46 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R47 1-216-198-11 RES-CHIP 1K 5% 1/8W
R48 1-216-198-11 RES-CHIP 1K 5% 1/8W
R49 1-216-198-11 RES-CHIP 1K 5% 1/8W
R50 1-216-198-11 RES-CHIP 1K 5% 1/8W
R51 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
< TRANSFORMER >
T1 1-419-514-11 COIL, IFT
< TUNER >
TU1 1-693-495-11 TUNER UNIT
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
MISCELLANEOUS
***************
15 1-792-256-11 CABLE, FFC (6P)
16 1-792-226-11 CABLE, FFC (15P)
55 1-792-225-11 CABLE, FFC (31P)
103 1-452-899-21 MAGNET
* 109 1-792-227-11 CABLE, FFC (CD PICK-UP)
* 163 1-794-105-11 HOUSING
185 1-792-511-11 WIRE (MM)
* 230 1-673-339-11 HEAD RELAY BOARD
* 232 1-794-104-11 HOUSING
0 251 8-848-483-05 PICK-UP, OPTICAL KSS-213C
255 X-2646-381-1 CHASSIS ASSY (MB) (RP), MOTOR (SPINDLE)
(INCLUDING M701)
0 308 1-575-651-11 CORD, POWER
0 F901 1-532-501-31 FUSE (0.8A)
0 F902 1-532-506-31 FUSE (6.3A)
HRPE3011-418-847-11 HEAD ASSY, HOLDER (REC/PB/ERASE)
M651 A-3320-538-A MOTOR ASSY, LOADING (LOADING)
M691 3-045-799-01 MOTOR ASSY (CAPSTAN/RELL)
(INCLUDING PULLEY)
M702 X-2625-769-1 GEAR ASSY, MOTOR
PH691 8-719-078-47 PHOTO INTERRUPTER SG-211V
PM691 1-454-896-11 SOLENOID, PLUNGER
S691 1-771-893-11 MODE (SW) (HEAD POSITION)
SP101 1-529-615-11 SPEAKER (8cm)
SP201 1-529-615-11 SPEAKER (8cm)
0 T901 1-435-350-11 TRANSFORMER, POWER
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
TUNER
To Next Page
