8-4
8-1-4. CHASSIS SECTION (HX710/HX910)
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
TU401
not
supplied
not
supplied
not
supplied
not
supplied
(HX710/HX910:RU,SP only)
not
supplied
not
supplied
154
155
157
158
161
160
156
162
152
152
152
164
163
159
165
168
167
152
152
152
152
166
158
152
161
151
153
152
152
152
168
168
161
151 3-086-778-01 FOOT
152 3-077-331-01 +BV3 (3-CR)
153 3-087-675-01 6-32UNCX5
154 1-787-291-11 FAN, D.C
155 3-089-380-01 DAMPER
156 2-159-920-01 SCREW, HDD DAMPER
157 1-830-755-21 CABLE, FLEXIBLE FLAT (FRH-002)
158 2-159-921-11 COVER,FLEXIBLE
0159 1-468-921-11 POWER SUPPLY BLOCK (HX910(TW))5
0159 1-468-930-11 POWER SUPPLY BLOCK
(HX710/HX910: RU, SP)
0159 1-468-932-11 POWER SUPPLY BLOCK (HX910: E)
DRIVE, DVD DRW-V35P
161 3-088-023-01 +B3 (3-CR)
162 2-159-921-11 COVER, FLEXIBLE
* 163 A-1121-027-A RD-051 (BS) S COMPL (HX910: E)
* 163 A-1121-034-A RD-051 (DS) S COMPL (HX910: RU)
* 163 A-1133-337-A RD-051 (BST) S COMPL (HX910: TW)
* 163 A-1138-665-A RD-051 (DSA) S COMPL (HX710)
* 163 A-1138-666-A RD-051 (DSS) S COMPL (HX910: SP)
164 1-830-665-11 CABLE, FLEXIBLE FLAT (FRD-002)
* 165 A-1121-030-A AV-089 (FS) COMPL (HX910: E)
* 165 A-1121-032-A AV-089 (HS) COMPL (HX910: TW)
* 165 A-1121-648-A AV-089 (JS) COMPL (HX710/HX910: RU, SP)
166 1-829-815-11 CABLE, FLEXIBLE FLAT (FAF-001)
167 3-088-022-01 +P3 (B TYPE) (3-CR)
168 3-077-331-31 +BV3 (3-CR)
169 1-830-443-11 CABLE, FLEXIBLE FLAT (FAE-007)
(HX710/HX910: RU, SP)
TU401 8-597-979-00 TUNER,FSS BTF-DF421 (HX710/HX910: RU, SP)
TU401 1-693-690-11 TUNER BTF-3WA401 (HX910:E,TW)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Note : The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
160 1-797-247-12
