Sony RDR-GX310 - Front Panel Section; Slide Door

2-3
2-3. FRONT PANEL SECTION
2-4. SLIDE DOOR
4 Front panel section
3 Seven claws
2 Ground spring
(FH55)
(GX310 only)
1 Two tapping screws
(+BV 3
x 8)
1 Tapping screws
(+B 2.6
x 6)
3 Tapping screw
s
(+B 2.6 x 6)
6 Slide door
5 Four claws
4 Door (spring)
2 Door (spring)
(HX710/HX910 only)
(HX710/HX910 only)
