8-25
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
RB1619 1-234-714-11 RES, NETWORK 56 (1005X4)
RB1620 1-234-400-21 CONDUCTOR, NETWORK (2010X4)
RB1621 1-234-400-21 CONDUCTOR, NETWORK (2010X4)
< VARIABLE RESISTOR >
RV801 1-223-583-41 RES, ADJ, CARBON (3 TYPE) 1K
< VIBRATOR >
X102 1-795-885-21 VIBRATOR, CRYSTAL (SMD) (33MHz)
X1001 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
X1901 1-795-886-21 VIBRATOR, CRYSTAL (SMD) (24.576MHz)
************************************************************
0 1-468-921-11 POWER SUPPLY BLOCK(GX310:TW/HX910:TW)
*************************************
<CAPACITOR>
0C101 FILM 0.22uF 250V
0C103 CERAMIC 330pF
0C104 CERAMIC 330pF
0C112 CERAMIC 1000pF
<CONNECTOR>
0CN101 AC INLET
<FUSE>
0F101 FUSE T3.15A/250V
0P301 FUSE,CHIP 1A
0P401 FUSE,CHIP 2.5A
0P501 FUSE,CHIP 2A
0P502 FUSE,CHIP 2A
0P601 FUSE,CHIP 0.8A
0P602 FUSE,CHIP 5A
<COIL>
0L101 LINE FILTER
0L102 LINE FILTER
<PHOTO COUPLER>
0PC101 PHOTO COUPLER
<RESISTOR>
0R101 CARBON 2.2M 1/2W
<TRANSFORMER>
0T101 TRANSFORMER,SWITCHING
<VARISTOR>
0Z101 VARISTOR S10K300
0 1-468-931-11 POWER SUPPLY BLOCK (GX310:E)
****************************
0 1-468-932-11 POWER SUPPLY BLOCK (HX910:E)
****************************
<CAPACITOR>
0C101 FILM,CHIP 0.22uf 275V
0C112 CERAMIC 470pF 250V
0C113 CERAMIC 470pF 250V
0C114 CERAMIC 470pF 250V
0C115 CERAMIC 100pF 250V
0C116 CERAMIC 100pF 250V
0C117 FILM,CHIP 0.1uf 275V
<CONNECTOR>
0CN101 AC INLET
<FUSE>
0F101 FUSE 3.15A/250V
0F301 FUSE 1A/250V
0F401 FUSE 2A/250V
0F402 FUSE 2A/250V
0F601 FUSE 3.15A/250V
0F701 FUSE 1A/250V
<COIL>
0L101 LINE FILTER 2A/20uH
0L102 LINE FILTER 0.8A/12mH
<PHOTO COUPLER>
0PC101 PHOTO COUPLER PS2561
<TRANSFORMER>
0T101 TRANSFORMER,CONVERTER
<VARISTOR>
0X101 VARISTOR ENE471D-10A
0 1-468-930-11 POWER SUPPLY BLOCK
(GX310:RU,SP/HX710/HX910:RU,SP)
**************************************
< CAPACITOR >
0C101 METAL 0.1u 250V
0C103 CERAMIC 100p
0C104 CERAMIC 100p
0C112 CERAMIC 1000p
< CONNECTOR >
0CN101 AC INLET
< FUSE >
0F101 FUSE T3.15A/250V
0P301 FUSE,CHIP 1A
0P401 FUSE,CHIP 2.5A
0P501 FUSE,CHIP 2A
0P502 FUSE,CHIP 2A
0P601 FUSE,CHIP 0.8A
0P602 FUSE.CHIP 5A
RD-051POWER SUPPLY BLOCK
Note : The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
