8-5
8-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* A-1121-013-A AV-089 (ES) COMPL (GX310: E)
*************************
* A-1121-030-A AV-089 (FS) COMPL (HX910: E)
*************************
* A-1121-015-A AV-089 (GS) COMPL (GX310: TW)
***************************
* A-1121-032-A AV-089 (HS) COMPL (HX910: TW)
***************************
* A-1121-020-A AV-089 (IS) COMPL (GX310: RU, SP)
*****************************
* A-1121-648-A AV-089 (JS) COMPL (HX710/HX910: RU, SP)
************************************
Ref.No.:10000 series
< CAPACITOR >
C101 1-126-947-11 ELECT 47uF 20% 35V
C104 1-137-921-31 ELECT 1500uF 20% 10V
C107 1-126-947-11 ELECT 47uF 20% 35V
C108 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C110 1-126-947-11 ELECT 47uF 20% 35V
C111 1-126-947-11 ELECT 47uF 20% 35V
C115 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C116 1-128-945-31 ELECT 1000uF 20% 10V
C120 1-165-714-31 ELECT 150uF 20% 6.3V
C121 1-165-714-31 ELECT 150uF 20% 6.3V
C124 1-126-926-11 ELECT 1000uF 20% 10V
(EXSEPT GX310:E/HX910:E)
C124 1-126-927-11 ELECT 2200uF 20% 10V
(GX310:E/HX910:E)
C126 1-126-947-11 ELECT 47uF 20% 35V
C127 1-126-947-11 ELECT 47uF 20% 35V
C128 1-126-947-11 ELECT 47uF 20% 35V
C129 1-126-947-11 ELECT 47uF 20% 35V
C132 1-128-952-31 ELECT 220uF 20% 25V
C133 1-126-947-11 ELECT 47uF 20% 35V
C140 1-126-963-11 ELECT 4.7uF 20% 50V
C206 1-126-947-11 ELECT 47uF 20% 35V
C207 1-126-947-11 ELECT 47uF 20% 35V
C208 1-126-947-11 ELECT 47uF 20% 35V
C209 1-126-947-11 ELECT 47uF 20% 35V
C210 1-126-963-11 ELECT 4.7uF 20% 50V
C212 1-126-963-11 ELECT 4.7uF 20% 50V
C213 1-126-947-11 ELECT 47uF 20% 35V
C214 1-126-947-11 ELECT 47uF 20% 35V
C215 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C216 1-126-964-11 ELECT 10uF 20% 50V
C217 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C218 1-126-947-11 ELECT 47uF 20% 35V
C219 1-126-961-11 ELECT 2.2uF 20% 50V
C220 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C221 1-126-947-11 ELECT 47uF 20% 35V
C222 1-126-964-11 ELECT 10uF 20% 50V
C225 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C226 1-165-883-11 CERAMIC CHIP 10000PF 10% 630V
C301 1-126-947-11 ELECT 47uF 20% 35V
C302 1-126-924-11 ELECT 330uF 20% 10V
C304 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C307 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C308 1-126-934-11 ELECT 220uF 20% 16V
C309 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C310 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C312 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C314 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C317 1-126-934-11 ELECT 220uF 20% 16V
C318 1-126-934-11 ELECT 220uF 20% 16V
C319 1-126-947-11 ELECT 47uF 20% 35V
C320 1-126-947-11 ELECT 47uF 20% 35V
C321 1-126-960-11 ELECT 1uF 20% 50V
C323 1-126-786-11 ELECT 47uF 20% 16V
C324 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C326 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C327 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C328 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C329 1-126-786-11 ELECT 47uF 20% 16V
C334 1-126-947-11 ELECT 47uF 20% 35V
C335 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C336 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C337 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(HX910: TW, E)
C338 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(HX910: TW, E)
C341 1-126-947-11 ELECT 47uF 20% 35V
C346 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C401 1-126-786-11 ELECT 47uF 20% 16V
C405 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C406 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C407 1-126-964-11 ELECT 10uF 20% 50V
C408 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C409 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C410 1-126-964-11 ELECT 10uF 20% 50V
C414 1-126-947-11 ELECT 47uF 20% 35V
(GX310:RU,SP/HX710/HX910:RU.SP)
C415 1-126-933-11 ELECT 100uF 20% 16V
C416 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
AV-089
Abbreviation
TW : Taiwan Model
RU : Russian Model
SP : Singapore Model
