2-4
2-6. EM-001 BOARD, EM BRACKET (GX310: RU, SP /HX710/HX910: RU, SP)
2-5. FL-144 BOARD, FR-226 BOARD (GX310)
FL-144 BOARD, FR-232 BOARD (HX710/HX910)
(CN102)
(CN1301)
6
Flexible flat cable
(FAF-001) (CN101)
1
Flexible flat cable
GX310 (FFL-002)
HX710/HX910 (FFS-001)
4
FL sheet (GX310)
FL cover (HX710/HX910)
7
Connector
(CN103)
3
Connector
(CN1302)
0
FR-226 board (GX310)
FR-232 board (HX710/HX910)
5
FL-114 board
9
Three tapping screws
(+BV 3
x
8)
2
Two tapping screws
(+BV 3
x
8)
8
Casorl
(HX710/HX910 only)
2
Flexible flat cable
(FAE-007) (CN302)
1
Flexible flat cable
(FAE-007) (CN301)
7
EM-001 board
5
Tapping screw
(+BV 3
x
8)
3
Two tapping screws
(+BV 3
x
10)
6
EM pwb bracket
4
Remove the EM-001 board assembly
in the direction of the arrow.
