2-9
2-14.AV-089 BOARD
2-15.CIRCUIT BOARDS LOCATION
2
Connector
(CN701)
3
Connector
(CN1201)
4
Connector
(CN3)
7
Six tapping screws
(+BV 3
x
10)
8
Three tapping screws
(+BV 3
x
8)
6
Screw
(+B 3
x
3)
0
Remove the AV-089 bpard
in the direction of the arrow.
5
Flexible flat cable
(FAF-001) (CN602)
9
Flexible flat cable
(FAE-007) (CN901/CN902)
(GX310:RU,SP/HX710/HX910:RU,SP only)
1
The pin that holds the
harness is set up.
Power supply block
AV-089 board
EM-001 board
(GX310:RU,SP/HX710/HX910:RU,SP
RD-051 board
FR-226 board (GX310)
FR-232 board (HX710/HX910)
FL-144 board
CN-243 board (HX710/HX910)
