Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
101
* C702 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C704 1-124-779-00 ELECT CHIP 10uF 20% 16V
C705 1-124-779-00 ELECT CHIP 10uF 20% 16V
C707 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C708 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
* C709 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C710 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C712 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C714 1-124-779-00 ELECT CHIP 10uF 20% 16V
C715 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
* C716 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C717 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C718 1-124-779-00 ELECT CHIP 10uF 20% 16V
C719 1-124-779-00 ELECT CHIP 10uF 20% 16V
C720 1-124-779-00 ELECT CHIP 10uF 20% 16V
C721 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C724 1-124-779-00 ELECT CHIP 10uF 20% 16V
C726 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
* C727 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C730 1-124-779-00 ELECT CHIP 10uF 20% 16V
C732 1-124-779-00 ELECT CHIP 10uF 20% 16V
C734 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C735 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
* C736 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C737 1-124-779-00 ELECT CHIP 10uF 20% 16V
C738 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C740 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C741 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C742 1-124-779-00 ELECT CHIP 10uF 20% 16V
C743 1-124-779-00 ELECT CHIP 10uF 20% 16V
C744 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C745 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C746 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
* C747 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C748 1-124-779-00 ELECT CHIP 10uF 20% 16V
C749 1-124-779-00 ELECT CHIP 10uF 20% 16V
C751 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C752 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C753 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C754 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C756 1-124-779-00 ELECT CHIP 10uF 20% 16V
* C757 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C758 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C759 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C761 1-124-779-00 ELECT CHIP 10uF 20% 16V
C763 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C764 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
* C765 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C766 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C767 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C904 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(HCDSHAKE100)
C906 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
(HCDSHAKE100)
C913 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C914 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C917 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
< CONNECTOR >
CN001 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN101 1-844-158-11 PIN, CONNECTOR (PC BOARD) 5P
CN102 1-820-825-81 CONNECTOR, FFC/FPC (LIF) 10P
CN105 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
CN107 1-778-384-51 CONNECTOR, FFC/FPC 16P
(FOR SERVICE USE)
CN109 1-820-121-51 CONNECTOR, FFC/FPC 23P
CN110 1-794-341-51 CONNECTOR, FFC/FPC 27P
CN301 1-844-159-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN302 1-843-557-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN303 1-794-362-51 CONNECTOR, FFC/FPC 5P
CN401 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN451 1-843-884-11 PIN, CONNECTOR (PC BOARD) 10P
CN503 1-843-881-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER WF L)
CN504 1-843-881-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER WF R)
CN505 1-843-882-11 PIN, CONNECTOR (PC BOARD) 8P
(LED SPEAKER SW L)
CN506 1-843-882-11 PIN, CONNECTOR (PC BOARD) 8P
(LED SPEAKER SW R)
CN601 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN851 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN901 1-843-885-11 PIN, CONNECTOR (PC BOARD) 2P
(HCDSHAKE100)
< DIODE >
D003 6-500-400-01 DIODE BAV99-215
D005 6-500-400-01 DIODE BAV99-215
D102 6-502-961-01 DI DA2J10100L
* D104 6-503-578-01 DI RB520SM-30T2R
* D105 6-503-578-01 DI RB520SM-30T2R
* D106 6-503-578-01 DI RB520SM-30T2R
* D107 6-503-578-01 DI RB520SM-30T2R
* D108 6-503-578-01 DI RB520SM-30T2R
* D109 6-503-578-01 DI RB520SM-30T2R
* D110 6-503-578-01 DI RB520SM-30T2R
* D111 6-503-578-01 DI RB520SM-30T2R
* D112 6-503-578-01 DI RB520SM-30T2R
* D113 6-503-578-01 DI RB520SM-30T2R
* D114 6-503-578-01 DI RB520SM-30T2R
* D115 6-503-578-01 DI RB520SM-30T2R
* D116 6-503-578-01 DI RB520SM-30T2R
* D117 6-503-578-01 DI RB520SM-30T2R
* D118 6-503-578-01 DI RB520SM-30T2R
* D119 6-503-578-01 DI RB520SM-30T2R
D401 8-719-069-29 DIODE RB520S-30FJTE61
D402 8-719-069-29 DIODE RB520S-30FJTE61
D571 6-502-961-01 DI DA2J10100L
D572 6-502-961-01 DI DA2J10100L
< FERRITE BEAD >
FB101 1-481-515-11 BEAD, FERRITE (1608)
< IC >
IC001 (Not supplied) IC TPS542941PWPR
IC002 (Not supplied) IC TPS542941PWPR
IC004 6-715-078-01 IC KIA7809AF/API
IC006 6-717-138-01 IC KIA7805AF-RTF/PW
IC101 6-721-336-01 IC R7S7200022CFP
IC102 6-707-866-01 IC TC74VHC126FT (EKJ)
IC103 6-719-856-01 IC BU4229F-TR
MOTHERBOARD
Ver. 1.2
Note: IC001 and IC002 on the MOTHERBOARD board
cannot exchange with single. When these parts on the
MOTHERBOARD board are damaged, exchange the entire
mounted board.
To Next Page
