Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
102
IC105 6-718-324-01 IC MFI337S3959
IC106 (Not supplied) IC MX25L3235EM2I-10G
IC301 6-716-478-01 IC CXD9990R (HCDSHAKE100)
IC301 6-718-440-01 IC CXD90013R (SHAKE99)
IC302 (Not supplied) IC W25Q32BVSSIG-R (HCDSHAKE100)
IC302 6-717-838-11 IC W25Q16CVSSIG-R (SHAKE99)
IC303 6-712-033-01 IC MM1701CHBE
IC304 6-714-351-01 IC R1EX24016ASAS0A (HCDSHAKE100)
IC305 6-717-694-01 IC BU33TD3WG-TR (HCDSHAKE100)
IC306 6-720-801-01 IC EM638165TSD-6G
IC401 6-720-195-01 IC AM5890S
* IC451 6-721-151-01 IC GL850G-OGY33
IC452 6-718-580-01 IC BA2903FV-E2
IC501 6-719-142-01 IC TC62D723FNG
IC502 6-719-142-01 IC TC62D723FNG
IC601 8-759-909-71 IC BA4558F
IC602 8-759-596-39 IC SN74LV4052APWR
IC603 8-759-909-71 IC BA4558F
IC604 6-705-973-01 IC PCM1754DBQR
IC605 8-759-596-39 IC SN74LV4052APWR
IC606 6-710-554-01 IC PCM1808PWR
IC607 8-759-680-48 IC TC7WH157FK
IC609 6-710-554-01 IC PCM1808PWR
IC610 6-707-800-01 IC SRC4182
IC611 6-705-973-01 IC PCM1754DBQR
IC612 8-759-909-71 IC BA4558F
IC613 6-705-973-01 IC PCM1754DBQR
IC614 8-759-909-71 IC BA4558F
IC615 6-705-973-01 IC PCM1754DBQR
IC616 8-759-909-71 IC BA4558F
IC901 6-720-187-01 IC NJM41031F1 (TE2) (HCDSHAKE100)
< JACK >
J602 1-774-411-11 JACK, PIN 6P
(AUDIO OUT L, PARTY CHAIN OUT R,
AUDIO IN 1 L, PARTY CHAIN IN R, AUDIO IN 2 L/R)
< JUMPER >
JC001 1-216-295-91 SHORT CHIP 0
JC002 1-216-295-91 SHORT CHIP 0
JC003 1-216-295-91 SHORT CHIP 0
JC004 1-216-295-91 SHORT CHIP 0
JC005 1-216-295-91 SHORT CHIP 0
JC006 1-216-295-91 SHORT CHIP 0
JC007 1-216-295-91 SHORT CHIP 0
JC008 1-216-295-91 SHORT CHIP 0
JC009 1-216-295-91 SHORT CHIP 0
JC010 1-216-295-91 SHORT CHIP 0
< COIL >
L001 1-460-359-11 INDUCTOR 4.7uH
L002 1-460-358-11 INDUCTOR 2.2uH
L003 1-400-789-21 INDUCTOR 2.2uH
L004 1-400-789-21 INDUCTOR 2.2uH
L006 1-457-439-11 INDUCTOR 4.7uH
L007 1-460-358-11 INDUCTOR 2.2uH
L008 1-400-789-21 INDUCTOR 2.2uH
< TRANSISTOR >
Q001 6-550-987-01 TR RN1911
Q002 6-553-509-01 TR KTA1542T-RTK/P
Q003 8-729-054-16 TRANSISTOR KRC402-RTK
Q004 6-553-509-01 TR KTA1542T-RTK/P
Q005 6-553-509-01 TR KTA1542T-RTK/P
Q006 8-729-054-16 TRANSISTOR KRC402-RTK
Q007 6-553-509-01 TR KTA1542T-RTK/P
Q008 6-553-509-01 TR KTA1542T-RTK/P
Q009 8-729-054-16 TRANSISTOR KRC402-RTK
Q103 6-553-509-01 TR KTA1542T-RTK/P
Q104 8-729-054-16 TRANSISTOR KRC402-RTK
Q107 8-729-054-16 TRANSISTOR KRC402-RTK
Q109 6-552-922-01 TR LTA014EUBFS8TL
Q401 6-551-120-01 TRANSISTOR 2SA2119K
Q402 6-551-120-01 TRANSISTOR 2SA2119K
Q571 8-729-054-16 TRANSISTOR KRC402-RTK
Q572 6-553-509-01 TR KTA1542T-RTK/P
Q574 6-552-967-01 TR RHK005N03T146
Q575 6-552-922-01 TR LTA014EUBFS8TL
Q576 8-729-054-16 TRANSISTOR KRC402-RTK
* Q602 6-551-959-01 TR IMX25T110
Q603 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q604 6-550-978-01 TR RN1902
Q605 8-729-427-72 TRANSISTOR XP4501
Q606 6-552-922-01 TR LTA014EUBFS8TL
Q607 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q611 6-550-978-01 TR RN1902
< RESISTOR >
R002 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R003 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R006 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R009 1-216-864-11 SHORT CHIP 0
R012 1-216-296-11 SHORT CHIP 0
R014 1-216-864-11 SHORT CHIP 0
R015 1-216-864-11 SHORT CHIP 0
R017 1-216-864-11 SHORT CHIP 0
R018 1-216-864-11 SHORT CHIP 0
R020 1-216-864-11 SHORT CHIP 0
R023 1-218-974-11 METAL CHIP 56K 5% 1/16W
R024 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R028 1-218-965-11 METAL CHIP 10K 5% 1/16W
R029 1-216-843-11 METAL CHIP 68K 5% 1/10W
R030 1-218-843-11 METAL CHIP 680 0.5% 1/10W
R031 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R033 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R034 1-216-813-11 METAL CHIP 220 5% 1/10W
R035 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R039 1-218-965-11 METAL CHIP 10K 5% 1/16W
R040 1-216-817-11 METAL CHIP 470 5% 1/10W
R041 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R043 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R047 1-216-864-11 SHORT CHIP 0
R048 1-216-864-11 SHORT CHIP 0
R051 1-216-295-91 SHORT CHIP 0
R052 1-216-295-91 SHORT CHIP 0
R053 1-216-864-11 SHORT CHIP 0
R054 1-216-864-11 SHORT CHIP 0
MOTHERBOARD
Note: IC106 and IC302 (HCDSHAKE100) on the MOTHERBOARD
board cannot exchange with single. When these parts on
the MOTHERBOARD board are damaged, exchange the
entire mounted board.
Ver. 1.2
