Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
107
R752 1-218-941-81 METAL CHIP 100 5% 1/16W
R753 1-218-941-81 METAL CHIP 100 5% 1/16W
R756 1-250-515-11 METAL CHIP 6.8K 1% 1/16W
R760 1-218-929-11 METAL CHIP 10 5% 1/16W
R761 1-218-929-11 METAL CHIP 10 5% 1/16W
R762 1-218-929-11 METAL CHIP 10 5% 1/16W
R763 1-216-864-11 SHORT CHIP 0
R764 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R765 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R766 1-218-941-81 METAL CHIP 100 5% 1/16W
R767 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R768 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R769 1-218-990-81 SHORT CHIP 0
R770 1-218-965-11 METAL CHIP 10K 5% 1/16W
R772 1-218-941-81 METAL CHIP 100 5% 1/16W
R773 1-218-965-11 METAL CHIP 10K 5% 1/16W
R774 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R775 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R776 1-216-864-11 SHORT CHIP 0
R778 1-218-990-81 SHORT CHIP 0
R779 1-218-929-11 METAL CHIP 10 5% 1/16W
R780 1-218-929-11 METAL CHIP 10 5% 1/16W
R781 1-218-929-11 METAL CHIP 10 5% 1/16W
R782 1-216-864-11 SHORT CHIP 0
R786 1-218-941-81 METAL CHIP 100 5% 1/16W
R787 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R788 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R789 1-218-990-81 SHORT CHIP 0
R790 1-218-965-11 METAL CHIP 10K 5% 1/16W
R792 1-216-864-11 SHORT CHIP 0
R793 1-216-864-11 SHORT CHIP 0
R794 1-216-864-11 SHORT CHIP 0
R795 1-218-929-11 METAL CHIP 10 5% 1/16W
R796 1-218-929-11 METAL CHIP 10 5% 1/16W
R797 1-218-929-11 METAL CHIP 10 5% 1/16W
R798 1-216-864-11 SHORT CHIP 0
R799 1-218-941-81 METAL CHIP 100 5% 1/16W
R800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R806 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R807 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R809 1-218-990-81 SHORT CHIP 0
R811 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R812 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R813 1-218-941-81 METAL CHIP 100 5% 1/16W
R814 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R815 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R816 1-218-990-81 SHORT CHIP 0
R817 1-218-929-11 METAL CHIP 10 5% 1/16W
R818 1-218-965-11 METAL CHIP 10K 5% 1/16W
R819 1-218-929-11 METAL CHIP 10 5% 1/16W
R820 1-218-929-11 METAL CHIP 10 5% 1/16W
R821 1-218-929-11 METAL CHIP 10 5% 1/16W
R822 1-218-929-11 METAL CHIP 10 5% 1/16W
R823 1-218-929-11 METAL CHIP 10 5% 1/16W
R851 1-218-990-81 SHORT CHIP 0
R852 1-218-990-81 SHORT CHIP 0
R853 1-218-990-81 SHORT CHIP 0
R854 1-218-990-81 SHORT CHIP 0
R855 1-218-990-81 SHORT CHIP 0
R856 1-218-990-81 SHORT CHIP 0
R857 1-216-864-11 SHORT CHIP 0
R859 1-216-864-11 SHORT CHIP 0
R905 1-218-990-81 SHORT CHIP 0 (HCDSHAKE100)
R906 1-218-973-11 METAL CHIP 47K 5% 1/16W
R907 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R908 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R910 1-218-990-81 SHORT CHIP 0
R911 1-218-985-11 METAL CHIP 470K 5% 1/16W
R912 1-218-985-11 METAL CHIP 470K 5% 1/16W
R913 1-218-975-11 METAL CHIP 68K 5% 1/16W
R914 1-218-975-11 METAL CHIP 68K 5% 1/16W
R915 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R916 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB301 1-234-370-21 RES, NETWORK 22 (1005X4)
RB302 1-234-370-21 RES, NETWORK 22 (1005X4)
RB303 1-234-370-21 RES, NETWORK 22 (1005X4)
RB304 1-234-370-21 RES, NETWORK 22 (1005X4)
RB305 1-234-370-21 RES, NETWORK 22 (1005X4)
RB306 1-234-370-21 RES, NETWORK 22 (1005X4)
RB307 1-234-370-21 RES, NETWORK 22 (1005X4)
RB308 1-234-370-21 RES, NETWORK 22 (1005X4)
RB309 1-234-370-21 RES, NETWORK 22 (1005X4)
< THERMISTOR >
TH571 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X101 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X102 1-814-767-11 QUARTZ CRYSTAL UNITS (13.333MHz)
X103 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz)
X451 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire LOADING ASSY (T).
*************************************************************
TUNER BOARD
************
< CAPACITOR >
C3000 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C3001 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C3002 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C3003 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C3004 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C3005 1-117-739-81 CERAMIC CHIP 3PF 0.1PF 16V
C3006 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C3007 1-117-739-81 CERAMIC CHIP 3PF 0.1PF 16V
* C3008 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3011 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C3013 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN3000 1-844-161-11 PIN, CONNECTOR (PC BOARD) 3P
(ANTENNA FM/AM)
CN3001 1-820-112-51 CONNECTOR, FFC/FPC 9P
Ver. 1.2
MOTHERBOARD
MS-476 TUNER
