Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
108
VOLUMEVIDEO
USB
< DIODE >
D3000 6-500-400-01 DIODE BAV99-215
D3001 6-500-400-01 DIODE BAV99-215
D3002 6-500-400-01 DIODE BAV99-215
< IC >
IC3000 6-720-234-01 IC RN5B801-0002
IC3001 6-715-134-01 IC MM3404A33URE
< COIL >
L3000 1-469-187-21 INDUCTOR 68nH
L3001 1-457-998-11 COIL, AM ANTENNA
L3002 1-469-187-21 INDUCTOR 68nH
L3003 1-414-576-41 INDUCTOR 47nH
L3004 1-414-455-11 INDUCTOR 2.2nH
< RESISTOR >
R3000 1-218-941-81 METAL CHIP 100 5% 1/16W
R3003 1-216-864-11 SHORT CHIP 0
R3004 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3005 1-218-941-81 METAL CHIP 100 5% 1/16W
R3006 1-218-990-81 SHORT CHIP 0
R3007 1-216-864-11 SHORT CHIP 0
R3008 1-218-933-11 METAL CHIP 22 5% 1/16W
R3009 1-218-933-11 METAL CHIP 22 5% 1/16W
R3010 1-216-864-11 SHORT CHIP 0
R3011 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X3000 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
*************************************************************
USB BOARD
**********
< CAPACITOR >
C2701 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C2703 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2705 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2706 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2707 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2708 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2710 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2711 1-126-382-11 ELECT 100uF 20% 16V
C2712 1-126-382-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN2700 1-819-866-11 USB CONNECTOR (A)
(REC/PLAY
B 5V 500mA)
CN2701 1-819-866-11 USB CONNECTOR (A) (PLAY A 5V 500mA)
CN2702 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D2201 6-503-388-01 DI 1L0352B13F0MIT02
D2202 6-503-388-01 DI 1L0352B13F0MIT02
D2700 6-502-970-01 DI DZ2J068M0L
D2701 6-502-970-01 DI DZ2J068M0L
D2702 6-502-970-01 DI DZ2J068M0L
D2703 6-502-970-01 DI DZ2J068M0L
D2704 6-502-970-01 DI DZ2J068M0L
D2705 6-502-970-01 DI DZ2J068M0L
D2708 6-500-400-01 DIODE BAV99-215
D2709 6-500-400-01 DIODE BAV99-215
D2710 6-500-400-01 DIODE BAV99-215
D2711 6-500-400-01 DIODE BAV99-215
D2712 6-500-400-01 DIODE BAV99-215
D2713 6-500-400-01 DIODE BAV99-215
< IC >
IC2700 6-600-766-01 IC PNA4823M01S0
< JUMPER >
JS2700 1-216-296-11 SHORT CHIP 0
JS2704 1-216-296-11 SHORT CHIP 0
JS2706 1-216-296-11 SHORT CHIP 0
JS2707 1-216-864-11 SHORT CHIP 0
JS2708 1-216-296-11 SHORT CHIP 0
JS2715 1-216-296-11 SHORT CHIP 0
JS2716 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R2700 1-216-801-11 METAL CHIP 22 5% 1/10W
R2701 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2702 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S2201 1-762-875-21 SWITCH, TACTILE (REC TO USB B)
S2202 1-762-875-21 SWITCH, TACTILE (ENTER)
*************************************************************
VIDEO BOARD (HCDSHAKE100)
************
< CAPACITOR >
C5000 1-162-964-91 CERAMIC CHIP 0.001uF 10% 50V
C5002 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
< CONNECTOR >
CN5000 1-843-885-11 PIN, CONNECTOR (PC BOARD) 2P
< JACK >
J5000 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< RESISTOR >
R5000 1-250-468-11 METAL CHIP 75 1% 1/16W
*************************************************************
VOLUME BOARD
*************
< CAPACITOR >
C2000 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2001 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2002 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2003 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2004 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2005 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2011 1-137-765-21 ELECT CHIP 47uF 20% 16V
C2012 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2013 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2014 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
TUNER
Ver. 1.2
