SS-SHAKE99/SHAKE100
SERVICE MANUAL
Sony Corporation
Published by Sony EMCS (Malaysia) PG Tec
SPEAKER SYSTEM
• SS-SHAKE99 is front speakers in SHAKE-99.
• SS-SHAKE99P is the package speaker of front speakers in SHAKE-99.
• SS-SHAKE100 is front speakers in SHAKE-100D.
• SSSHAKE100P is the package speaker of front speakers in SHAKE-100D.
SPECIFICATIONS
Ver. 1.2 2014.07
9-890-635-03
2014G80-1
©
2014.07
Speakers
SS-SHAKE99 for SHAKE-99
SS-SHAKE100 for SHAKE-100D
Speaker system
4-way, Sound Pressure Horn and Bass Refl ex
Speaker unit
Woofers: 250 mm (9
7
/
8
in), cone type
Tweeters: 25 mm (1 in), horn type
Mid speakers: 100 mm (4 in), cone type
Subwoofers: 460 mm (18 in), cone type
Rated impedance
Mid speakers/tweeters: 8 ohms
Woofers: 10 ohms
Subwoofers: 8 ohms
Dimensions (w/h/d) (Approx.)
610 mm × 945 mm × 500 mm
(24
1
/
8
in × 37
1
/
4
in × 19
3
/
4
in)
Mass (Approx.)
51.0 kg (112 lb 7 oz)
Quantity: 2 pieces
Design and specifi cations are subject to change without notice.
• JIG
When disassembling the set, use the following jig (for front panel
removal).
Part No.: J-2501-238-A JIG FOR SPEAKER REMOVAL
US Model
E Model
Argentina Model
Australian Model
Mexican Model
SS-SHAKE99
Malaysia Model
Saudi Arabia Model
South African Model
SS-SHAKE100
SS-SHAKE99/SHAKE100
SS-SHAKE99P/SSSHAKE100P
To Next Page
