HCD-SHAKE99/HCDSHAKE100
75
Pin No. Pin Name I/O Description
163 Vss - Ground terminal
164 MTK-POWER-CTRL O Power Control pin for MTK
165 C-CONT O Trigger port to start charging of SPM
166 Q-Flash-SIO2 I QSPI: Data I/O pins for channel 0
167 Q-Flash-SIO3 I QSPI: Data I/O pins for channel 0
168 Q-Flash-CLK O Clock signal to QSPI
169 Q-Flash-CS O Slave select pin to QSPI
170 Q-Flash-SIO0 I QSPI: Data I/O pins for channel 0
171 Vss - Ground terminal
172 Q-Flash-SIO1 I QSPI: Data I/O pins for channel 0
173 MIC-DETECT I Mic Input Detection pin. “H”: Mic detected
174 PVcc - Power supply terminal (+3.3V)
175 LINK-SET O Party Chain output bias pin
176 LINK-OUT-A O Selector A for Party Chain Signal
Ver. 1.1
