HCD-SHAKE99/HCDSHAKE100
74
Pin No. Pin Name I/O Description
109 PVcc - Power supply terminal (+3.3V)
110 TEST-MON4/SD_D0_0 O Test port for software checking.
111
ANALOG-CSEL/
SD_D1_0
O Multiplexer selector C for Analog input
112
RGB-TRANS-LED-
SPK/SD_WP_0
O Transfer signal to RGB driver (driver for Speaker LED)
113
RGB-TRANS-LED/
SD_CD_0
O Transfer signal to RGB driver
114 ST-RDS I Input for RDS Text Detect Signal (L: RDS Detect)
115 ST-CE O Tuner IC: Tuner enable input pin
116 Vss - G round ter minal
117 PCONT-DAMP O Digital Amp Module Power Control Pin. “H”: ON
118 RGB-PWM-CLK O PWM clock signal to RGB driver
119 Vcc - Power supply terminal (+3.3V)
120 /AMP-RESET O Digital Amp Reset Pin
121 Vss - Ground terminal
122 CD-MOTOR+ O CDM turning motor control signal output
123 PVcc - Power supply terminal (+3.3V)
124 CD-MOTOR- O CDM turning motor control signal output
125 CP-CLK O Clock signal for CP IC.
126 CP-DATA O Data signal for CP IC.
127 ST-CLK O Tuner IC: Clock signal for IIC communication
128 ST-DATA O Tuner IC: Data signal for IIC communication
129 NFC-IRQ I NFC wireless data receive signal input from the NFC section
130 /PS-PROTECT I Power Supply Protection Detection Pin. “L”: Protect on
131 /AMP-SD I Digital Amp over current protection pin. “L”: Protect on
132 /DC-DET I DC detection pin. “L: Protect on
133 BT-TxD O TX signal output terminal for Bluetooth section
134 FL-BK O Blinking signal to FL CIG
135 SIRCS I Remote control signal input
136 AMP-CLK-FR O Clock to front Amp
137 RGB-SCLK O Serial clock output to RGB driver
138 Vss - Ground terminal
139 USB-X1 - Not used
140 USB-X2 - Not used
141 USBDPVcc - Power supply terminal (+3.3V)
142 USBDVss - Not used
143 DM1 - Not used
144 DP1 - Not used
145 VBUSIN1 - Not used
146 USBDVcc - Power supply terminal (+3.3V)
147 USBVss - Not used
148 USBDPVcc - Power supply terminal (+3.3V)
149 USBDPVss - Not used
150 DM0 - Not used
151 DP0 - Not used
152 VBUSIN0 - Not used
153 USBDVcc - Power supply terminal (+3.3V)
154 USBDVss - Not used
155 REFIN - Not used
156 USBAPVss - Not used
157 USBAPVcc - Power supply terminal (+3.3V)
158 USBAVcc - Power supply terminal (+3.3V)
159 USBAVss - Not used
160 USBUVcc - Power supply terminal (+3.3V)
161 USBUVss - Not used
162 Vss - Ground terminal
