Pin No. Pin Name I/O Description
55 SSI1_DI I Data In Signal from ADC to Aragon
56 PCONT-BTSTBY O BT Standby Power Control Pin. “H”: ON
57
PCONT-PSAVE-PRO-
TECT
O Main power on/off control signal output “H”:power on
58 Vcc - Power supply terminal (+3.3V)
59 LINK-DET I Party Chain input bias detection pin
60 NFC-DATA I Two-way data bus with the NFC
61 Vss - Ground terminal
62 PVcc - Power supply terminal (+3.3V)
63 AC-CUT I AC off detection signal input from the reset signal IC “L”: AC Cut detected
64 DEBUG-RxD I RxD (for Debug)
65 BT-RxD I RX input signal from Bluetooth section
66 SS-DET I Speaker detection pin. “L”: Speaker detected
67 RTC-X1 - Not used
68 RTC-X2 -Not used
69 PLLVcc - Power supply terminal (+3.3V)
70 EXTAL - Not used
71 XTAL - Not used
72 Vss - Ground terminal
73 Vss - Ground terminal
74 NMI - Non-maskable interrupt input terminal
75 Vss - Ground terminal
76 RES - Reset signal
77 PVcc - Power supply terminal (+3.3V)
78 AMP-TEMP-MON I Temperature protect pin. “L”: Protect on
79 SPM-C-MON I Voice coil temperature monitor pin.
80 SPM-AMBIENT-TEMP I Ambient temperature monitor pin.
81 MODEL-DEST-IN I Model and Destination setting terminal (A/D input)
82 INT-FAN-DET I Fan speed detection pin
83 MASTER-VOLUME I Jog dial pulse input from the MASTER VOLUME encoder (A/D input)
84 AD-KEY0 I Key input terminal (A/D input)
85 AD-KEY1 I Key input terminal (A/D input)
86 AVcc - Power supply terminal (+3.3V)
87 AVss - Ground terminal
88 AVref - A/D Converter reference voltage input terminal (+3.3V)
89 BSCANP - Boundary scan setting pin
90 PVcc - Power supply terminal (+3.3V)
91 AUDIO-X1 - Not used
92 AUDIO-X2 - Not used
93 Vss - Ground terminal
94 /LINE-MUTE O Muting Control Switch for Party Chain. “L”: mute On
95 Vcc - Power supply terminal (+3.3V)
96 /LINE-MUTE-FR O Muting Control Switch for Speaker. “L”: mute On
97 TRST - Debugging interface: Initialization-signal input pin.
98 TDO - Debugging interface: Serial output pin for instructions and data.
99 TDI - Debugging interface: Serial input pin for instructions and data.
100 TMS - Debugging interface: Test-mode select signal input pin
101 TCK - Debugging interface: Test-clock input pin
102 Vss - Ground terminal
103 TEST-MON0/SD_D2_0 O Test port for software checking.
104 TEST-MON1/SD_D3_0 O Test port for software checking.
105 Vcc - Power supply terminal (+3.3V)
106
TEST-MON2/SD_
CMD_0
O Test port for software checking.
107 Vss - Ground terminal
108 TEST-MON3/SD_CLK O Test port for software checking.
