HCD-SHAKE99/HCDSHAKE100
80
Pin No. Pin Name I/O Description
111 ADACVSS1 - Ground terminal
112 ACLK O Master clock signal output to the A/D converter and D/A converter
113 ABCK O Bit clock signal output to the A/D converter and D/A converter
114 NC - Not used
115 AVCM I Audio D/A converter reference voltage terminal
116 NC - Not used
117 ALRCK O L/R sampling clock signal output to the A/D converter and D/A converter
118 ASDATA0 O Audio data output to the D/A converter
119 ADACVDD1 - Power supply terminal (+3.3V)
120 ADACVDD2 - Power supply terminal (+3.3V)
121 AVDD12_1 - Power supply terminal (+1.2V)
122 AGND12 - Ground terminal
123 RFIP I AC coupled RF signal input from the optical pick-up block
124 RFIN I AC coupled RF signal input from the optical pick-up block
125 IOPMON/OPO I Power monitor terminal
126 SPFG/OP I Spindle motor hall sensor input from the motor driver
127 RF_B I RF main beam A input from the optical pick-up block
128 RF_A I RF main beam B input from the optical pick-up block
