Sony SHAKE-99D - Page 98

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
96
R1718 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1719 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1722 1-218-446-11 METAL CHIP 1 5% 1/10W
R1723 1-218-446-11 METAL CHIP 1 5% 1/10W
R1724 1-218-446-11 METAL CHIP 1 5% 1/10W
R1725 1-218-446-11 METAL CHIP 1 5% 1/10W
< TERMINAL >
TB1000 1-854-090-11 SPEAKER TERMINAL JACK
(LEFT SPEAKERS SW WF MID/TW
IMPEDANCE USE 8Ω 10Ω 8Ω GRAY)
TB1001 1-854-079-11 SPEAKER TERMINAL JACK
(RIGHT SPEAKERS MID/TW WF SW
IMPEDANCE USE 8Ω 10Ω 8Ω BLACK)
< THERMISTOR >
0 TH1000 1-804-045-11 THERMISTOR
0 TH1001 1-804-045-11 THERMISTOR
0 TH1002 1-804-045-11 THERMISTOR
0 TH1003 1-804-045-11 THERMISTOR
0 TH1004 1-804-045-11 THERMISTOR
0 TH1005 1-804-045-11 THERMISTOR
0 TH1006 1-804-045-11 THERMISTOR
0 TH1007 1-804-045-11 THERMISTOR
0 TH1008 1-804-045-11 THERMISTOR
0 TH1009 1-804-045-11 THERMISTOR
*************************************************************
BUTTON LEFT BOARD
******************
< CONNECTOR >
CN2300 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D2101 6-503-224-02 DI 1L0352V22F3MIT02
D2102 6-503-388-01 DI 1L0352B13F0MIT02
D2103 6-503-224-02 DI 1L0352V22F3MIT02
D2104 6-503-224-02 DI 1L0352V22F3MIT02
D2105 6-503-224-02 DI 1L0352V22F3MIT02
D2106 6-503-224-02 DI 1L0352V22F3MIT02
< RESISTOR >
R2300 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2301 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2302 1-216-819-11 METAL CHIP 680 5% 1/10W
R2303 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2305 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2306 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2307 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2308 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2309 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2310 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
< SWITCH >
S2101 1-762-875-21 SWITCH, TACTILE (+/1)
S2102 1-762-875-21 SWITCH, TACTILE
(BLUETOOTH CONNECTION - PAIRING)
S2103 1-762-875-21 SWITCH, TACTILE (BASS BAZUCA)
S2104 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FLANGER)
S2105 1-762-875-21 SWITCH, TACTILE (MUSIC - PARTY CHAIN)
S2106 1-762-875-21 SWITCH, TACTILE (DJ EFFECT ISOLATOR)
S2107 1-762-875-21 SWITCH, TACTILE (MOVIE/GAME)
S2108 1-762-875-21 SWITCH, TACTILE (DJ EFFECT PAN)
S2109 1-762-875-21 SWITCH, TACTILE (FOOTBALL)
S2110 1-762-875-21 SWITCH, TACTILE (DJ EFFECT WAH)
S2111 1-762-875-21 SWITCH, TACTILE (NX)
S2112 1-762-875-21 SWITCH, TACTILE (
.m TUNING–)
S2113 1-762-875-21 SWITCH, TACTILE (x)
*************************************************************
BUTTON RIGHT BOARD
*******************
< CONNECTOR >
CN2400 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN2401 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< RESISTOR >
R2400 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2401 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2402 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2403 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2404 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2405 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R2406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2407 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2408 1-216-819-11 METAL CHIP 680 5% 1/10W
R2409 1-216-835-11 METAL CHIP 15K 5% 1/10W
< SWITCH >
S2001 1-762-875-21 SWITCH, TACTILE (
+)
S2002 1-762-875-21 SWITCH, TACTILE (M> TUNING+)
S2003 1-762-875-21 SWITCH, TACTILE ( – )
S2004 1-762-875-21 SWITCH, TACTILE (OPTIONS)
S2005 1-762-875-21 SWITCH, TACTILE
(CD) (SHAKE99)/(DVD/CD) (HCDSHAKE100)
S2006 1-762-875-21 SWITCH, TACTILE (LED COLOR)
S2007 1-762-875-21 SWITCH, TACTILE (USB/USB SELECT)
S2008 1-762-875-21 SWITCH, TACTILE (LED PATTERN)
S2009 1-762-875-21 SWITCH, TACTILE (TUNER/BAND)
S2010 1-762-875-21 SWITCH, TACTILE (ZOPEN/CLOSE)
S2011 1-762-875-21 SWITCH, TACTILE (AUDIO IN)
*************************************************************
A-1977-052-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C2202 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C2203 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2204 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2205 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2206 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2207 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2208 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C2209 1-126-382-11 ELECT 100uF 20% 16V
C2211 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C2212 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C2213 1-126-795-11 ELECT 10uF 20% 50V
C2214 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
10CH DAMP BUTTON LEFT BUTTON RIGHT DISPLAY
Ver. 1.1
