Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE99/HCDSHAKE100
97
C2215 1-126-382-11 ELECT 100uF 20% 16V
C2216 1-114-326-11 CERAMIC CHIP 0.22uF 10% 25V
C2217 1-114-326-11 CERAMIC CHIP 0.22uF 10% 25V
C2218 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2219 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN2200 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D2200 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2203 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2204 6-502-970-01 DI DZ2J068M0L
D2205 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2206 6-503-775-01 DI CRH02 (T5R, SONY, XM)
< FLUORESCENT INDICATOR TUBE >
FL2212 1-483-465-11 VACUUM FLUORESCENT DISPLAY
< JUMPER >
JS2200 1-216-296-11 SHORT CHIP 0
JS2201 1-216-296-11 SHORT CHIP 0
JS2202 1-216-296-11 SHORT CHIP 0
JS2205 1-216-296-11 SHORT CHIP 0
JS2206 1-216-296-11 SHORT CHIP 0
< COIL >
LL2211 1-412-541-21 INDUCTOR 220uH
< TRANSISTOR >
Q2200 6-553-392-01 TR PBSS8110T
Q2201 6-553-392-01 TR PBSS8110T
< RESISTOR >
R2200 1-216-809-11 METAL CHIP 100 5% 1/10W
R2201 1-216-809-11 METAL CHIP 100 5% 1/10W
R2202 1-216-809-11 METAL CHIP 100 5% 1/10W
R2203 1-216-809-11 METAL CHIP 100 5% 1/10W
R2204 1-216-797-11 METAL CHIP 10 5% 1/10W
R2205 1-216-797-11 METAL CHIP 10 5% 1/10W
R2206 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2207 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2208 1-257-172-91 METAL CHIP 100 5% 1/3W
R2209 1-257-172-91 METAL CHIP 100 5% 1/3W
R2210 1-218-446-11 METAL CHIP 1 5% 1/10W
< TRANSFORMER >
T2200 1-697-233-11 DC-DC CONVERTER TRANSFORMER
*************************************************************
LED BAR LEFT BOARD
******************
< CONNECTOR >
CN2800 1-778-622-51 CONNECTOR, FFC/FPC 10P
< DIODE >
D2801 6-503-944-51 DI SMLVN6RGB1U17QYB
D2802 6-503-944-51 DI SMLVN6RGB1U17QYB
*************************************************************
LED BAR RIGHT BOARD
*******************
< CONNECTOR >
CN2900 1-778-622-51 CONNECTOR, FFC/FPC 10P
< DIODE >
D2902 6-503-944-51 DI SMLVN6RGB1U17QYB
D2904 6-503-944-51 DI SMLVN6RGB1U17QYB
*************************************************************
MIC BOARD
*********
< CAPACITOR >
C2600 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2604 1-126-956-91 ELECT 0.1uF 20% 50V
C2605 1-126-964-11 ELECT 10uF 20% 50V
C2606 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2607 1-126-961-11 ELECT 2.2uF 20% 50V
C2608 1-126-956-91 ELECT 0.1uF 20% 50V
C2609 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C2610 1-126-956-91 ELECT 0.1uF 20% 50V
C2611 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C2612 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C2613 1-126-923-91 ELECT 220uF 20% 10V
C2614 1-165-696-21 CERAMIC CHIP 0.1uF 10% 25V
C2615 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2616 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2617 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C2618 1-126-923-91 ELECT 220uF 20% 10V
C2619 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2620 1-126-961-11 ELECT 2.2uF 20% 50V
C2622 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2623 1-126-961-11 ELECT 2.2uF 20% 50V
C2624 1-126-961-11 ELECT 2.2uF 20% 50V
C2626 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2627 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D2600 6-502-961-01 DI DA2J10100L
D2601 6-500-400-01 DIODE BAV99-215
< IC >
IC2600 8-759-909-71 IC BA4558F
< JACK >
J2600 1-822-757-11 JACK (LARGE TYPE) (MIC IN)
< JUMPER >
JS2600 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q2600 6-552-891-01 TR LSAR523UBFS8TL
Q2601 6-552-967-01 TR RHK005N03T146
< RESISTOR >
R2600 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2601 1-216-857-11 METAL CHIP 1M 5% 1/10W
DISPLAY LED BAR LEFT LED BAR RIGHT
MIC
