2-1
Note: Follow the disassembly procedure in the numerical order given.
2-1. UPPER CASE REMOVAL 2-3. POWER BLOCK (SRV938EK) REMOVAL
2-2. REAR PANEL REMOVAL
2-4. FRONT PANEL SECTION REMOVAL
SECTION 2
DISASSEMBLY
SLV-SE610/SE710/SE810/SX710/SX717/SX810/X9
1 Two screws
(Case3 TP2)
2 Two screws
(Case3 TP2)
3 Upper case
2 Harness
4 Two claws
(EXCEPT SE610)
5 Two claws
(EXCEPT SE610: A, G, K, N)
6 Two claws
(SE610: A, G, K, N)
8 Rear panel
1 Power cord
(CN101)
3 Two claws
7 Two claws
3 Three screws
(B3)
1 Connector
(CN202)
2 Connector
(CN201)
4 Claw
5 Power block
(SRV938EK)
2 Connector (CN501)
(SE810/SX810/X9)
1 Flat cable (FDS-9/10)
(CN461)
5 Two claws
3 Two claws
4 Two claws
6 Front panel section
