NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Not all of the parts for POWER BLOCK
(SRV938EK) are listed.
8-2. ELECTRICAL PARTS LIST
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DS-95 JK-201
* A-6794-810-A DS-95 BOARD, COMPLETE
(SE610/SE710/SX710/SX717)
* A-6794-812-A DS-95 BOARD, COMPLETE (SE810/SX810/X9)
*********************
(Ref.No. 1,000 Series)
< CONNECTOR >
CN450 1-770-514-31 CONNECTOR, FFC/FPC 5P (SE810/SX810/X9)
CN451 1-770-519-31 CONNECTOR, FFC/FPC 11P (SE810/SX810/X9)
CN453 1-770-514-31 CONNECTOR, FFC/FPC 5P
(SE610/SE710/SX710/SX717)
< DIODE >
D450 8-719-056-06 DIODE SLR-342DCT31 (JOG)
(SE810/SX810/X9)
< SHORT >
JS450 1-216-295-11 SHORT 0
(SE610/SE710/SX710/SX717)
< TRANSISTOR >
Q450 8-729-043-29 TRANSISTOR PDTC144EK-115
(SE810/SX810/X9)
< RESISTOR >
R450 1-249-408-11 CARBON 180 5% 1/4W F
(SE810/SX810/X9)
R451 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R452 1-249-417-11 CARBON 1K 5% 1/4W F
R453 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R454 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R455 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R456 1-249-425-11 CARBON 4.7K 5% 1/4W F
R457 1-249-417-11 CARBON 1K 5% 1/4W F
R458 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S410 1-418-156-11 ENCODER, ROTARYRY (DIAL TIMER)
(SE810/SX810/X9)
S450 1-786-097-21 SWITCH, TACT (z)
S451 1-786-097-21 SWITCH, TACT (m)
S452 1-786-097-21 SWITCH, TACT (x)
(SE610/SE710/SX710/SX717)
S453 1-786-097-21 SWITCH, TACT (N)
(SE610/SE710/SX710/SX717)
S454 1-786-097-21 SWITCH, TACT (JOG) (SE810/SX810/X9)
S455 1-786-097-21 SWITCH, TACT (M)
S456 1-786-097-21 SWITCH, TACT (X)
S457 1-786-097-21 SWITCH, TACT (A)
* A-6794-811-A JK-201 BOARD, COMPLETE (SE810/SX810/X9)
***********************
(Ref.No. 1,000 Series)
< CAPACITOR >
C481 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C491 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C493 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D480 8-719-070-59 DIODE PDZ6.8B-115
D481 8-719-067-40 DIODE STZ6.8N-T146
D490 8-719-067-40 DIODE STZ6.8N-T146
D491 8-719-067-40 DIODE STZ6.8N-T146
< JACK >
J481 1-695-865-11 JACK, PIN 3P (LINE-2 IN)
< RESISTOR >
R480 1-216-022-00 METAL CHIP 75 5% 1/10W
R490 1-216-817-11 METAL CHIP 470 5% 1/16W
R491 1-216-817-11 METAL CHIP 470 5% 1/16W
