Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
117
STR-DA2000ES/DB2000
R1833 1-216-864-11 SHORT CHIP 0
R1835 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1836 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1839 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1842 1-216-864-11 SHORT CHIP 0
R1847 1-216-809-11 METAL CHIP 100 5% 1/10W
R1848 1-216-809-11 METAL CHIP 100 5% 1/10W
R1849 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1850 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1851 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R1889 1-215-921-11 METAL OXIDE 4.7K 5% 3W F
R1890 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1891 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1892 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1893 1-216-809-11 METAL CHIP 100 5% 1/10W
R1894 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1895 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1896 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1897 1-216-864-11 SHORT CHIP 0
R1899 1-216-864-11 SHORT CHIP 0
R1901 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1902 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1903 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1904 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1905 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1906 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1907 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1908 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1911 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1912 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1913 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1915 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1916 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1917 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1918 1-216-845-11 METAL CHIP 100K 5% 1/10W
(STR-DA2000ES)
R1921 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1922 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1923 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1924 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1925 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1926 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1927 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1928 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1931 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1932 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1933 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1935 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1936 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1938 1-216-833-11 METAL CHIP 10K 5% 1/10W
(STR-DA2000ES)
R1941 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1942 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1943 1-216-805-11 METAL CHIP 47 5% 1/10W
R1944 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1945 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1946 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1947 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1952 1-216-809-11 METAL CHIP 100 5% 1/10W
R1953 1-216-809-11 METAL CHIP 100 5% 1/10W
R1954 1-216-809-11 METAL CHIP 100 5% 1/10W
R1955 1-216-809-11 METAL CHIP 100 5% 1/10W
R1956 1-216-809-11 METAL CHIP 100 5% 1/10W
R1957 1-216-809-11 METAL CHIP 100 5% 1/10W
R1970 1-216-809-11 METAL CHIP 100 5% 1/10W
R1971 1-216-809-11 METAL CHIP 100 5% 1/10W
R1972 1-216-809-11 METAL CHIP 100 5% 1/10W
R1980 1-216-809-11 METAL CHIP 100 5% 1/10W
R1981 1-216-809-11 METAL CHIP 100 5% 1/10W
R1982 1-216-809-11 METAL CHIP 100 5% 1/10W
R1983 1-216-809-11 METAL CHIP 100 5% 1/10W
R1984 1-216-809-11 METAL CHIP 100 5% 1/10W
R1985 1-216-809-11 METAL CHIP 100 5% 1/10W
R1986 1-216-809-11 METAL CHIP 100 5% 1/10W
R1987 1-216-809-11 METAL CHIP 100 5% 1/10W
R1988 1-216-864-11 SHORT CHIP 0
R1989 1-216-864-11 SHORT CHIP 0
R1991 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1992 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1993 1-216-809-11 METAL CHIP 100 5% 1/10W
R1994 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1995 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1996 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1997 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2853 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R2854 1-249-393-11 CARBON 10 5% 1/4W
R2868 1-216-013-00 RES-CHIP 33 5% 1/10W
R2887 1-216-198-00 RES-CHIP 1K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R2887 1-259-995-11 CARBON MELF 1K 2% 1/8W
(STR-DB2000: AEP, UK)
R2888 1-216-013-00 RES-CHIP 33 5% 1/10W
R2889 1-216-246-00 RES-CHIP 100K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R2889 1-260-020-11 CARBON MELF 100K 2% 1/8W
(STR-DB2000: AEP, UK)
R2890 1-216-246-00 RES-CHIP 100K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R2890 1-260-020-11 CARBON MELF 100K 2% 1/8W
(STR-DB2000: AEP, UK)
R2891 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R2891 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
(STR-DB2000: AEP, UK)
R2892 1-216-174-00 RES-CHIP 100 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R2892 1-259-983-11 CARBON MELF 100 2% 1/8W
(STR-DB2000: AEP, UK)
R2893 1-216-198-00 RES-CHIP 1K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R2893 1-259-995-11 CARBON MELF 1K 2% 1/8W
(STR-DB2000: AEP, UK)
< RELAY >
RY1480 1-755-486-11 RELAY
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
D. AMP
