Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
118
STR-DA2000ES/DB2000
D. AMP DIGITAL
RY1680 1-755-170-11 RELAY (12V)
RY1690 1-755-170-11 RELAY (12V)
RY2851 1-755-486-11 RELAY
< THERMISTOR >
TH1791 1-810-641-21 CHIP, THERMISTOR
TH1792 1-810-641-21 CHIP, THERMISTOR
TH1793 1-810-641-21 CHIP, THERMISTOR
TH1794 1-810-641-21 CHIP, THERMISTOR
TH1795 1-810-641-21 CHIP, THERMISTOR
TH1796 1-810-641-21 CHIP, THERMISTOR (STR-DA2000ES)
< TERMINAL >
TM1710 1-780-024-11 TERMINAL BOARD (SP) (8P)
(FRONT SPEAKERS IMPEDANCE USE 4-16Ω)
(STR-DA2000ES)
TM1710 1-780-024-21 TERMINAL BOARD (SP) (8P)
(FRONT SPEAKER IMPEDANCE USE 4-16Ω)
(STR-DB2000)
TM1730 1-694-992-11 TERMINAL BOARD (SP) (2P)
(CENTER SPEAKERS IMPEDANCE USE 4-16Ω)
(STR-DA2000ES)
TM1730 1-780-025-21 TERMINAL BOARD (SP) (2P)
(CENTER SPEAKERS IMPEDANCE USE 4-16Ω)
(STR-DB2000)
TM1740 1-694-992-11 TERMINAL BOARD (SP) (2P)
(SURROUND SPEAKERS IMPEDANCE USE
4-16Ω L) (STR-DA2000ES)
TM1740 1-780-025-21 TERMINAL BOARD (SP) (2P)
(SURROUND SPEAKERS IMPEDANCE USE
4-16Ω L) (STR-DB2000)
TM1750 1-694-992-11 TERMINAL BOARD (SP) (2P)
(SURROUND SPEAKERS IMPEDANCE USE
4-16Ω R) (STR-DA2000ES)
TM1750 1-780-025-21 TERMINAL BOARD (SP) (2P)
(SURROUND SPEAKERS IMPEDANCE USE
4-16Ω R) (STR-DB2000)
TM1760 1-694-992-11 TERMINAL BOARD (SP) (2P)
(SURROUND BACK SPEAKERS IMPEDANCE
USE 4-16Ω L) (STR-DA2000ES)
TM1760 1-780-025-21 TERMINAL BOARD (SP) (2P)
(SURROUND BACK SPEAKER IMPEDANCE
USE 4-16Ω) (STR-DB2000)
TM1770 1-694-992-11 TERMINAL BOARD (SP) (2P)
(SURROUND BACK SPEAKERS IMPEDANCE
USE 4-16Ω R)(STR-DA2000ES)
< VIBRATOR >
X1471 1-795-660-21 QUARTZ CRYSTAL UNIT (49.125MHz)
X1800 1-579-952-21 VIBRATOR, CERAMIC (8MHz)
************************************************************
A-4733-922-A DIGITAL BOARD, COMPLETE (STR-DA2000ES)
A-4734-045-A DIGITAL BOARD, COMPLETE
(STR-DB2000: SP, MY)
A-4734-054-A DIGITAL BOARD, COMPLETE
(STR-DB2000: AEP, UK)
***********************
< CAPACITOR >
C2001 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2002 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2003 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2004 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2005 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2007 1-126-967-11 ELECT 47uF 20% 50V
(STR-DA2000ES)
C2007 1-128-860-11 ELECT 47uF 20% 50V
(STR-DB2000: SP, MY)
C2007 1-135-746-11 ELECT 47uF 50V
(STR-DB2000: AEP, UK)
C2009 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2010 1-126-916-11 ELECT 1000uF 20% 6.3V
(STR-DA2000ES)
C2010 1-135-656-91 ELECT 1000uF 6.3V
(STR-DB2000: AEP, UK)
C2010 1-137-658-91 ELECT 1000uF 20% 6.3V
(STR-DB2000: SP, MY)
C2011 1-126-964-11 ELECT 10uF 20% 50V
(STR-DA2000ES)
C2011 1-119-824-11 ELECT 10uF 20% 50V
(STR-DB2000: SP, MY)
C2011 1-135-743-11 ELECT 10uF 50V
(STR-DB2000: AEP, UK)
C2012 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2013 1-135-711-91 ELECT 470uF 16V
(STR-DB2000: AEP, UK)
C2014 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000: AEP, UK)
C2016 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2017 1-126-935-11 ELECT 470uF 20% 16V
(STR-DA2000ES)
C2017 1-127-720-91 ELECT 470uF 20% 16V
(STR-DB2000: SP, MY)
C2017 1-135-711-91 ELECT 470uF 16V
(STR-DB2000: AEP, UK)
C2026 1-126-964-11 ELECT 10uF 20% 50V
(STR-DA2000ES)
C2026 1-119-824-11 ELECT 10uF 20% 50V
(STR-DB2000: SP, MY)
C2026 1-135-743-11 ELECT 10uF 50V
(STR-DB2000: AEP, UK)
C2027 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2028 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2029 1-126-964-11 ELECT 10uF 20% 50V
(STR-DA2000ES)
C2029 1-119-824-11 ELECT 10uF 20% 50V
(STR-DB2000: SP, MY)
C2029 1-135-743-11 ELECT 10uF 50V
(STR-DB2000: AEP, UK)
C2030 1-126-964-11 ELECT 10uF 20% 50V
(STR-DA2000ES)
C2030 1-119-824-11 ELECT 10uF 20% 50V
(STR-DB2000: SP, MY)
C2030 1-135-743-11 ELECT 10uF 50V
(STR-DB2000: AEP, UK)
C2031 1-126-963-11 ELECT 4.7uF 20% 50V
(STR-DA2000ES)
C2031 1-119-823-11 ELECT 4.7uF 20% 50V
(STR-DB2000: SP, MY)
C2031 1-135-743-11 ELECT 10uF 50V
(STR-DB2000: AEP, UK)
C2032 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2033 1-165-319-11 CERAMIC CHIP 0.1uF 50V
