Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
135
STR-DA2000ES/DB2000
R1205 1-216-022-00 RES-CHIP 75 5% 1/10W
R1207 1-216-022-00 RES-CHIP 75 5% 1/10W
R1211 1-216-022-00 RES-CHIP 75 5% 1/10W
R1212 1-216-022-00 RES-CHIP 75 5% 1/10W
R1214 1-216-022-00 RES-CHIP 75 5% 1/10W
R1216 1-216-022-00 RES-CHIP 75 5% 1/10W
R1218 1-216-022-00 RES-CHIP 75 5% 1/10W
R1241 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1242 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R1243 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R1244 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1246 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1247 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1248 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1249 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1250 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1251 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1261 1-216-035-00 RES-CHIP 270 5% 1/10W
(STR-DA2000ES)
R1271 1-216-035-00 RES-CHIP 270 5% 1/10W
(STR-DB2000)
R1272 1-216-121-11 RES-CHIP 1M 5% 1/10W
(STR-DB2000)
R1273 1-216-035-00 RES-CHIP 270 5% 1/10W
(STR-DB2000)
R1274 1-216-121-11 RES-CHIP 1M 5% 1/10W
(STR-DB2000)
R1275 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DB2000)
R1276 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DB2000)
R1277 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DB2000: AEP, UK)
R1277 1-216-174-00 RES-CHIP 100 5% 1/8W
(STR-DB2000: SP, MY)
R1281 1-216-037-00 RES-CHIP 330 5% 1/10W
(STR-DB2000)
R1282 1-216-037-00 RES-CHIP 330 5% 1/10W
(STR-DB2000)
R1283 1-216-101-00 RES-CHIP 150K 5% 1/10W
(STR-DB2000)
R1284 1-216-101-00 RES-CHIP 150K 5% 1/10W
(STR-DB2000)
R1285 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R1290 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R1291 1-216-033-00 RES-CHIP 220 5% 1/10W
(STR-DA2000ES)
R1292 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
(STR-DA2000ES)
R1293 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R1294 1-216-073-00 RES-CHIP 10K 5% 1/10W
(STR-DA2000ES)
R1295 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
(STR-DA2000ES)
R1296 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
(STR-DA2000ES)
R1297 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(STR-DA2000ES)
R1298 1-216-073-00 RES-CHIP 10K 5% 1/10W
(STR-DA2000ES)
R1299 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(STR-DA2000ES)
0R1300 1-249-393-11 CARBON 10 5% 1/4W F
(STR-DA2000ES)
< VARIABLE RESISTOR >
RV111 1-241-759-11 RES, ADJ, CARBON 220
RV141 1-241-759-11 RES, ADJ, CARBON 220
RV161 1-241-759-11 RES, ADJ, CARBON 220
RV181 1-241-759-11 RES, ADJ, CARBON 220
RV211 1-241-759-11 RES, ADJ, CARBON 220
RV241 1-241-759-11 RES, ADJ, CARBON 220
RV281 1-241-759-11 RES, ADJ, CARBON 220
< RELAY >
RY1290 1-755-359-11 RELAY (STR-DA2000ES)
< VIBRATOR >
X1261 1-781-821-21 VIBRATOR, CRYSTAL (14.31MHz)
(STR-DA2000ES)
X1271 1-781-821-21 VIBRATOR, CRYSTAL (14.31MHz)
(STR-DB2000)
X1272 1-781-820-21 VIBRATOR, CRYSTAL (17.734MHz)
(STR-DB2000)
************************************************************
A-4733-941-A REG BOARD, COMPLETE (STR-DA2000ES)
A-4734-035-A REG BOARD, COMPLETE
(STR-DB2000: SP, MY)
A-4734-064-A REG BOARD, COMPLETE
(STR-DB2000: AEP, UK)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C905 1-137-150-11 MYLAR 0.01uF 5% 100V
C906 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C907 1-127-720-91 ELECT 470uF 20% 16V
(EXCEPT STR-DB2000: AEP, UK)
C907 1-135-711-91 ELECT 470uF 16V
(STR-DB2000: AEP, UK)
C908 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C909 1-128-858-11 ELECT 22uF 20% 50V
(EXCEPT STR-DB2000: AEP, UK)
C909 1-135-703-91 ELECT 22uF 25V
(STR-DB2000: AEP, UK)
C909 1-135-710-91 ELECT 220uF 16V
(STR-DB2000: AEP, UK)
C910 1-128-889-51 ELECT 470uF 20% 100V
(EXCEPT STR-DB2000: AEP, UK)
C910 1-135-733-51 ELECT 470uF 100V
(STR-DB2000: AEP, UK)
C911 1-100-188-11 MYLAR 0.75uF 5% 250V
C913 1-100-691-11 ELECT 10000uF 20% 63V
C914 1-100-188-11 MYLAR 0.75uF 5% 250V
C915 1-127-718-91 ELECT 100uF 20% 16V
C916 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C917 1-127-718-91 ELECT 100uF 20% 16V
MULTI-VIDEO REG
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
