Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
136
STR-DA2000ES/DB2000
REG SP TM (A) SP TM (B)
C918 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C919 1-127-718-91 ELECT 100uF 20% 16V
C920 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C921 1-135-660-51 ELECT 6800uF 6.3V
(STR-DB2000: AEP, UK)
C921 1-137-662-91 ELECT 6800uF 20% 6.3V
(EXCEPT STR-DB2000: AEP, UK)
C922 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C923 1-135-660-51 ELECT 6800uF 6.3V
(STR-DB2000: AEP, UK)
C923 1-137-662-91 ELECT 6800uF 20% 6.3V
(EXCEPT STR-DB2000: AEP, UK)
C924 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C925 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C926 1-127-718-91 ELECT 100uF 20% 16V
C927 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C928 1-127-718-91 ELECT 100uF 20% 16V
< CONNECTOR >
CN901 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
(STR-DB2000: AEP, UK)
CN902 1-784-922-11 PIN, CONNECTOR 5P
CN903 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
(STR-DB2000: AEP, UK)
CN904 1-564-321-00 PIN, CONNECTOR 2P (STR-DB2000: AEP, UK)
CN905 1-564-321-00 PIN, CONNECTOR 2P (STR-DB2000)
CN906 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
(STR-DB2000: AEP, UK)
CN907 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN908 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
(STR-DB2000: AEP, UK)
CN909 1-784-926-11 PIN, CONNECTOR 11P
* CN910 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D901 8-719-988-61 DIODE 1SS355TE-17
D902 8-719-988-61 DIODE 1SS355TE-17
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 8-719-053-18 DIODE 1SR154-400TE-25
D905 8-719-053-18 DIODE 1SR154-400TE-25
D906 8-719-069-56 DIODE UDZSTE-176.2B
D907 8-719-016-74 DIODE 1SS352
< EARTH TERMINAL >
* EP901 4-924-264-21 TERMINAL, MOUNT
* EP902 4-924-264-21 TERMINAL, MOUNT
* EP903 1-537-738-21 TERMINAL, EARTH
* EP904 1-537-738-21 TERMINAL, EARTH
* EP905 1-537-738-21 TERMINAL, EARTH
< IC/TRANSISTOR >
IC903 8-759-545-66 IC NJM3414AMP (TE2)
IC911 8-759-445-59 IC BA033T
IC912 8-759-231-53 IC TA7805S
* IC913 8-729-045-93 TRANSISTOR IMZ4T108
< COIL >
L901 1-421-967-11 INDUCTOR 100uH
L902 1-421-967-11 INDUCTOR 100uH
< TRANSISTOR >
Q01 8-729-620-05 TRANSISTOR 2SC2603-EF
Q905 8-729-216-31 TRANSISTOR 2SA1163-G
Q906 8-729-271-31 TRANSISTOR 2SC2713-G
Q908 8-729-271-31 TRANSISTOR 2SC2713-G
Q911 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q912 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q913 6-550-363-01 TRANSISTOR 2SB1690KT146
Q914 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R905 1-249-589-31 CARBON 36K 5% 1/4W
R906 1-216-025-11 RES-CHIP 100 5% 1/10W
R907 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R908 1-216-369-00 METAL OXIDE 1 5% 2W
R909 1-216-113-00 RES-CHIP 470K 5% 1/10W
R910 1-216-073-00 RES-CHIP 10K 5% 1/10W
R911 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R912 1-216-077-00 RES-CHIP 15K 5% 1/10W
R913 1-216-049-11 RES-CHIP 1K 5% 1/10W
R914 1-216-295-00 SHORT CHIP 0
R915 1-216-025-11 RES-CHIP 100 5% 1/10W
R916 1-216-073-00 RES-CHIP 10K 5% 1/10W
R917 1-215-869-11 METAL OXIDE 1K 5% 1W
R918 1-216-041-11 RES-CHIP 470 5% 1/10W
R919 1-216-049-11 RES-CHIP 1K 5% 1/10W
R920 1-216-049-11 RES-CHIP 1K 5% 1/10W
R921 1-216-073-00 RES-CHIP 10K 5% 1/10W
R922 1-249-607-31 CARBON 200K 5% 1/4W
R927 1-249-958-11 CARBON 30K 5% 1/4W
R928 1-249-937-11 CARBON 2.9K 5% 1/4W
R929 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R930 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R931 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
************************************************************
1-860-490-11 SP TM (A) BOARD
***************
< CAPACITOR >
CC004 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC005 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC011 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC012 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC018 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC019 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC025 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC026 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-491-11 SP TM (B) BOARD
***************
< CAPACITOR >
CC051 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC052 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
