Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
137
STR-DA2000ES/DB2000
1-860-492-11 SP TM (C) BOARD
***************
< CAPACITOR >
CC055 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC056 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-493-11 SP TM (D) BOARD
***************
< CAPACITOR >
CC059 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC060 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-494-11 SP TM (E) BOARD
***************
< CAPACITOR >
CC063 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC064 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-495-11 SP TM (F) BOARD
***************
< CAPACITOR >
CC067 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC068 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-496-11 SP TM (G) BOARD
***************
< CAPACITOR >
CC071 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC072 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-497-11 SP TM (H) BOARD
***************
< CAPACITOR >
CC075 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC076 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-498-11 SP TM (I) BOARD
**************
< CAPACITOR >
CC079 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC080 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-499-11 SP TM (J) BOARD (STR-DA2000ES)
***************
< CAPACITOR >
CC083 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC084 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-500-11 SP TM (K) BOARD (STR-DA2000ES)
***************
< CAPACITOR >
CC087 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC088 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
A-4733-944-A S-VIDEO BOARD, COMPLETE
(STR-DA2000ES)
A-4734-037-A S-VIDEO BOARD, COMPLETE (STR-DB2000)
************************
< CAPACITOR >
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C703 1-126-964-11 ELECT 10uF 20% 50V
C704 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C705 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C706 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C707 1-126-964-11 ELECT 10uF 20% 50V
C708 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C726 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C727 1-126-964-11 ELECT 10uF 20% 50V
C731 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C732 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C733 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C734 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN701 1-568-444-11 SOCKET, CONNECTOR 13P
CN753 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D701 8-719-801-78 DIODE 1SS184
D761 8-719-016-74 DIODE 1SS352
D766 8-719-016-74 DIODE 1SS352
< IC >
IC701 6-704-199-01 IC NJM2595M-TE2
IC702 6-704-199-01 IC NJM2595M-TE2
< JACK >
J701 1-764-676-11 CONNECTOR (ROUND TYPE)
(DVD S-VIDEO IN, TV/SAT S-VIDEO IN)
J705 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO1 S-VIDEO IN, VIDEO1 S-VIDEO OUT)
J709 1-537-943-11 TERMINAL, S (MONITOR S-VIDEO OUT)
J751 1-817-726-11 JACK, PIN 9P
(TV-SAT IN, DVD IN, MONITOR OUT)
< TRANSISTOR >
Q761 8-729-230-49 TRANSISTOR 2SC2712-YG
Q766 8-729-230-49 TRANSISTOR 2SC2712-YG
SP TM (C) SP TM (D) SP TM (E)
SP TM (F) SP TM (G) SP TM (H) SP TM (I) SP TM (J) SP TM (K) S-VIDEO
