Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
138
STR-DA2000ES/DB2000
< RESISTOR >
R701 1-216-022-00 RES-CHIP 75 5% 1/10W
R702 1-216-022-00 RES-CHIP 75 5% 1/10W
R703 1-216-022-00 RES-CHIP 75 5% 1/10W
R704 1-216-022-00 RES-CHIP 75 5% 1/10W
R705 1-216-022-00 RES-CHIP 75 5% 1/10W
R706 1-216-022-00 RES-CHIP 75 5% 1/10W
R707 1-216-022-00 RES-CHIP 75 5% 1/10W
R708 1-216-022-00 RES-CHIP 75 5% 1/10W
R709 1-216-022-00 RES-CHIP 75 5% 1/10W
R710 1-216-022-00 RES-CHIP 75 5% 1/10W
R712 1-216-295-00 SHORT CHIP 0
R713 1-216-295-00 SHORT CHIP 0
R721 1-216-295-00 SHORT CHIP 0
R760 1-216-295-00 SHORT CHIP 0
R761 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R762 1-216-073-00 RES-CHIP 10K 5% 1/10W
R766 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R767 1-216-073-00 RES-CHIP 10K 5% 1/10W
< RELAY >
RY761 1-755-184-11 RELAY
RY762 1-755-184-11 RELAY
RY766 1-755-184-11 RELAY
RY767 1-755-184-11 RELAY
************************************************************
1-688-684-11 TH BOARD
*********
< THERMISTOR (POSITIVE) >
THP901 1-817-728-11 SENSOR, THERMISTOR
************************************************************
A-4728-955-A UP CONVERT BOARD, COMPLETE
(STR-DA2000ES)
***************************
< CAPACITOR >
C3100 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C3101 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C3102 1-126-947-11 ELECT 47uF 20% 35V
C3103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3104 1-126-947-11 ELECT 47uF 20% 35V
C3105 1-104-665-11 ELECT 100uF 20% 25V
C3106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3107 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3108 1-126-959-11 ELECT 0.47uF 20% 50V
C3109 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3110 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3111 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3112 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C3113 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3114 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3115 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3117 1-104-665-11 ELECT 100uF 20% 25V
C3118 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C3119 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C3120 1-126-947-11 ELECT 47uF 20% 35V
C3121 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3123 1-104-665-11 ELECT 100uF 20% 25V
C3124 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C3125 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C3126 1-130-495-00 MYLAR 0.1uF 5% 50V
C3127 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
C3128 1-126-961-11 ELECT 2.2uF 20% 50V
C3129 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3130 1-126-963-11 ELECT 4.7uF 20% 50V
C3131 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3132 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C3133 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C3134 1-126-959-11 ELECT 0.47uF 20% 50V
C3135 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C3136 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3137 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C3138 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CN3101 1-766-724-11 CONNECTOR, BOARD TO BOARD 7P
< FERRITE BEAD >
FB3101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3102 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3103 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC3100 8-759-678-99 IC TC90A45F
IC3101 8-759-826-19 IC MM1093NF
< JUMPER RESISTOR >
JW3121 1-216-295-00 SHORT CHIP 0
JW3122 1-216-295-00 SHORT CHIP 0
JW3123 1-216-295-00 SHORT CHIP 0
< COIL >
L3100 1-412-064-11 INDUCTOR 100uH
L3101 1-412-011-31 INDUCTOR 27uH
L3102 1-412-064-11 INDUCTOR 100uH
L3103 1-412-011-31 INDUCTOR 27uH
L3104 1-412-011-31 INDUCTOR 27uH
L3105 1-414-194-11 INDUCTOR 33uH
< TRANSISTOR >
Q3100 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3102 8-729-216-22 TRANSISTOR 2SA1162-G
Q3103 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3104 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3105 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3106 8-729-216-22 TRANSISTOR 2SA1162-G
Q3107 8-729-216-22 TRANSISTOR 2SA1162-G
Q3108 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3109 8-729-230-49 TRANSISTOR 2SC2712-YG
Q3110 8-729-230-49 TRANSISTOR 2SC2712-YG
S-VIDEO TH UP CONVERT
