Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
139
STR-DA2000ES/DB2000
UP CONVERT VOL
Q3111 8-729-216-22 TRANSISTOR 2SA1162-G
Q3112 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R3101 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3102 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R3103 1-216-043-00 RES-CHIP 560 5% 1/10W
R3104 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3105 1-216-047-00 RES-CHIP 820 5% 1/10W
R3106 1-216-047-00 RES-CHIP 820 5% 1/10W
R3107 1-216-075-00 RES-CHIP 12K 5% 1/10W
R3108 1-216-043-00 RES-CHIP 560 5% 1/10W
R3110 1-216-047-00 RES-CHIP 820 5% 1/10W
R3111 1-216-047-00 RES-CHIP 820 5% 1/10W
R3112 1-216-043-00 RES-CHIP 560 5% 1/10W
R3113 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3114 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R3115 1-216-043-00 RES-CHIP 560 5% 1/10W
R3116 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3117 1-216-047-00 RES-CHIP 820 5% 1/10W
R3118 1-216-025-11 RES-CHIP 100 5% 1/10W
R3120 1-216-075-00 RES-CHIP 12K 5% 1/10W
R3121 1-216-043-00 RES-CHIP 560 5% 1/10W
R3122 1-260-354-71 CARBON 150K 5% 1/2W
R3123 1-216-047-00 RES-CHIP 820 5% 1/10W
R3124 1-216-043-00 RES-CHIP 560 5% 1/10W
R3125 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3126 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R3127 1-216-043-00 RES-CHIP 560 5% 1/10W
R3128 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R3129 1-216-047-00 RES-CHIP 820 5% 1/10W
R3130 1-216-025-11 RES-CHIP 100 5% 1/10W
R3131 1-216-039-00 RES-CHIP 390 5% 1/10W
R3132 1-216-075-00 RES-CHIP 12K 5% 1/10W
R3133 1-216-043-00 RES-CHIP 560 5% 1/10W
R3134 1-260-354-71 CARBON 150K 5% 1/2W
R3136 1-216-073-00 RES-CHIP 10K 5% 1/10W
R3137 1-216-073-00 RES-CHIP 10K 5% 1/10W
R3138 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3139 1-216-077-00 RES-CHIP 15K 5% 1/10W
R3140 1-216-121-11 RES-CHIP 1M 5% 1/10W
R3141 1-216-039-00 RES-CHIP 390 5% 1/10W
R3142 1-216-022-00 RES-CHIP 75 5% 1/10W
R3143 1-216-022-00 RES-CHIP 75 5% 1/10W
R3144 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3145 1-216-045-00 RES-CHIP 680 5% 1/10W
R3146 1-216-035-00 RES-CHIP 270 5% 1/10W
< VIBRATOR >
X3100 1-781-342-21 OSCILLATOR, CRYSTAL (3.5795MHz)
************************************************************
1-688-601-11 VOL BOARD
**********
< CONNECTOR >
CN1060 1-779-978-11 PIN, CONNECTOR 3P
< VARIABLE RESISTOR >
RV1060 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
************************************************************
MISCELLANEOUS
**************
57 1-773-297-11 WIRE (FLAT TYPE) (29 CORE)
63 1-500-472-11 CORE, FERRITE (STR-DA2000ES)
153 1-400-550-11 FILTER, CLAMP
0 154 1-769-744-11 CORD, POWER (EXCEPT US, CND)
0 154 1-783-820-11 CORD, POWER (US, CND)
202 1-769-875-11 WIRE (FLAT TYPE) (7 CORE) (STR-DA2000ES)
203 1-769-969-11 WIRE (FLAT TYPE) (13 CORE)
206 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
(EXCEPT STR-DB2000: AEP, UK)
206 1-773-001-11 WIRE (FLAT TYPE) (15 CORE)
(STR-DB2000: AEP, UK)
254 1-500-051-11 CORE, FERRITE
255 1-469-241-11 CORE, FERRITE
256 1-469-969-11 CLAMP, FERRITE (STR-DA2000ES)
257 1-500-603-11 CLAMP, FERRITE (STR-DA2000ES)
303 1-469-969-11 CLAMP, FERRITE
304 1-773-220-11 WIRE (FLAT TYPE) (25 CORE)
306 1-500-169-11 CORE (FPC) (STR-DA200ES)
IC904 8-759-231-53 IC TA7805S
IC905 8-759-071-48 IC TA7807S
IC906 8-759-245-79 IC TA79005S
IC909 8-759-445-59 IC BA033T
IC910 8-759-231-53 IC TA7805S
Q904 6-550-625-01 TRANSISTOR 2SK 1381
Q909 6-702-390-01 IC MN2488-0PY-MK
TU2051 1-693-577-31 TUNER (STR-DA2000ES)
TU2051 1-693-578-41 TUNER (STR-DB2000: AEP, UK)
TU2051 1-693-641-11 TUNER (STR-DB2000: SP, MY)
************************************************************
ACCESSORIES
************
1-477-793-11 COMMANDER, STANDARD (RM-PP412)
(STR-DB2000)
1-477-843-11 COMMANDER, STANDARD (RM-LG112)
(STR-DA2000ES)
1-501-594-14 ANTENNA (FM) (STR-DB2000)
1-754-149-11 LOOP ANT (AM)
1-793-184-23 CONNECTOR (F TYPE ADAPTOR) (FM)
(STR-DA2000ES)
3-071-119-01 COVER, BATTERY (for RM-LG112/RM-PP412)
4-247-241-13 MANUAL, INSTRUCTION (ENGLISH)
4-247-241-23 MANUAL, INSTRUCTION
(FRENCH) (CND, AEP, SP, MY)
4-247-241-33 MANUAL, INSTRUCTION (SPANISH)
(AEP, SP, MY)
4-247-241-43 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN) (AEP)
4-247-241-53 MANUAL, INSTRUCTION
(SWEDISH, POLISH) (AEP)
4-247-241-63 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (SP, MY)
4-247-242-11 MANUAL, INSTRUCTION (POLTUGUESE) (AEP)
