— 43 —
51 4-216-926-01 SUB-CHASSIS
52 1-672-994-11 HEADPHONE BOARD
54 X-4947-124-1 FOOT ASSY (F50150S) (SILVER) (DE435:AEP)
54 X-4947-207-1 FOOT ASSY (F50150S) (BLACK)
(DE435:AEP,EE,CIS,MY,SP,AUS/DE535:E,MY,SP,AUS/V424)
54 X-4947-208-1 FOOT ASSY (F50150S)
(D435:US,CND/DE535:US,CND/SE491)
54 X-4947-547-1 FOOT ASSY (F50150S) (V525)
56 4-985-642-01 CUSHION
58 1-672-995-11 STANDBY BOARD
59 1-672-991-11 BRIDGE-A BOARD
60 A-4419-080-A P.AMP BOARD, COMPLETE
(DE435:US/DE535:US)
60 A-4419-205-A P.AMP BOARD, COMPLETE
(DE435:CND/DE535:CND/SE491)
60 A-4419-208-A P.AMP BOARD, COMPLETE
(DE435:MY,SP,AUS/DE535:MY,SP,AUS/V424/V525)
60 A-4419-214-A P.AMP BOARD, COMPLETE (DE535:E)
60 A-4419-233-A P.AMP BOARD, COMPLETE (DE435:AEP,EE,CIS)
* 61 3-655-653-21 BAND (TAITON), BINDING
62 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
63 A-4419-074-A REAR AMP BOARD, COMPLET
(EXCEPT AEP,EE,CIS)
63 A-4419-229-A REAR AMP BOARD, COMPLET (AEP,EE,CIS)
* 64 3-703-244-00 BUSHING (2104), CORD
! 65 1-696-847-11 CORD, POWER (DE435:AUS/DE535:AUS)
! 65 1-777-070-21 CORD, POWER (DE435:CND/DE535:CND)
! 65 1-777-071-21 CORD, POWER
(DE435:AEP,EE,CIS,MY,SP/DE535:E,MY,SP)
! 65 1-783-205-11 CORD, POWER (V424/V525)
! 65 1-783-820-11 CORD, POWER (DE435:US/DE535:US/SE491)
66 4-216-927-01 BACK PANEL (DE535:US)
66 4-216-927-11 BACK PANEL (DE535:CND)
66 4-216-927-21 BACK PANEL (DE535:AUS)
66 4-216-927-31 BACK PANEL (DE535:E)
66 4-216-927-41 BACK PANEL (DE535:MY,SP)
66 4-216-927-51 BACK PANEL (V525)
66 4-217-181-01 BACK PANEL (DE435:US)
66 4-217-181-11 BACK PANEL (DE435:CND)
66 4-217-181-21 BACK PANEL (DE435:AUS)
66 4-217-181-31 BACK PANEL (DE435:MY,SP)
66 4-217-181-41 BACK PANEL (V424)
66 4-217-181-51 BACK PANEL (DE435:AEP)
66 4-217-181-61 BACK PANEL (DE435:EE,CIS)
66 4-217-181-71 BACK PANEL (SE491)
67 A-4419-076-A REAR SPK BOARD, COMPLET
(DE535:US,CND,E)
67 A-4419-207-A REAR SPK BOARD, COMPLET
(DE535:MY,SP,AUS/V525)
67 A-4419-218-A REAR SPK BOARD, COMPLET
(DE435:US,CND/SE491)
67 A-4419-224-A REAR SPK BOARD, COMPLET
(DE435:MY,SP,AUS/V424)
67 A-4419-230-A REAR SPK BOARD, COMPLET
(DE435:AEP,EE,CIS)
68 A-4419-083-A SURR BOARD, COMPLETE (DE535/V525)
68 A-4419-203-A SURR BOARD, COMPLETE (SE491)
68 A-4419-221-A SURR BOARD, COMPLETE
(DE435:US,CND,MY,SP,AUS/V424)
68 A-4419-234-A SURR BOARD, COMPLETE (DE435:AEP,EE,CIS)
69 1-773-008-11 WIRE (FLAT TYPE) (15 CORE)
70 1-769-942-11 WIRE (FLAT TYPE) (11 CORE)
71 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
72 4-924-098-91 HOLDER, PC BOARD
73 1-693-407-62 TUNER
(DE435:US,CND/DE535:US,CND,E/SE491)
73 1-693-408-41 TUNER
(DE435:AEP,MY,SP,AUS/DE535:MY,SP,AUS/V424/V525)
73 1-693-411-43 TUNER (DE435:EE,CIS)
74 1-773-004-11 WIRE (FLAT TYPE) (15 CORE)
75 A-4419-079-A INPUT BOARD, COMPLETE
(DE535/SE491/V525)
75 A-4419-220-A INPUT BOARD, COMPLETE
(DE435:US,CND,MY,SP,AUS/V424)
75 A-4419-232-A INPUT BOARD, COMPLETE (DE435:AEP,EE,CIS)
76 1-672-992-11 BRIDGE-B BOARD
77 3-905-609-01 SCREW (TRANSISTOR)
! 78 1-569-008-21 ADAPTOR, CONVERSION 2P (DE535: E)
79 1-672-996-11 VOLTAGE SELECTOR BOARD (DE535:E)
Q705 8-729-209-15 TRANSISTOR 2SD2012
Q706 8-749-010-25 IC MN2488-OPY-M
Q707 8-749-010-26 IC MP1620-OPY-M
Q755 8-729-209-15 TRANSISTOR 2SD2012
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
! T901 1-433-679-11 TRANSFORMER, POWER
(DE435:CND/DE535:CND)
! T901 1-433-680-11 TRANSFORMER, POWER
(DE435:US/DE535:US)
! T901 1-433-680-21 TRANSFORMER, POWER (SE491)
! T901 1-433-681-11 TRANSFORMER, POWER (DE435:AEP,EE,CIS)
! T901 1-433-682-11 TRANSFORMER, POWER
(DE435:AUS/DE535:AUS)
! T901 1-433-683-11 TRANSFORMER, POWER
(DE435:MY,SP/DE535:MY,SP/V424/V525)
! T901 1-433-684-11 TRANSFORMER, POWER (DE535:E)
