Sony STR-DE435 - Input Key

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 50 —
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-439-11 CARBON 68K 5% 1/4W
R754 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT AEP,EE,CIS)
R754 1-249-442-11 CARBON 510 5% 1/4W
(AEP,EE,CIS)
R790 1-249-433-11 CARBON 22K 5% 1/4W
< VIBRATOR >
X230 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz(AEP,EE,CIS)
************************************************************
A-4419-078-A KEY BOARD, COMPLETE (DE535/SE491/V525)
********************
A-4419-219-A KEY BOARD, COMPLETE
********************
(EXCEPT AEP,EE,CIS/DE535/SE491/V525)
A-4419-231-A KEY BOARD, COMPLETE (AEP,EE,CIS)
********************
< CONNECTOR >
CNS110 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
CNS111 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
CNS112 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
< DIODE >
D119 8-719-046-39 DIODE SEL5821A-TP15 (DE535/SE491/V525)
(TUNER)
D120 8-719-046-39 DIODE SEL5821A-TP15 (TUNER)
D123 8-719-046-39 DIODE SEL5821A-TP15 (DE535/SE491/V525)
(CD)
D124 8-719-046-39 DIODE SEL5821A-TP15 (CD)
D125 8-719-046-39 DIODE SEL5821A-TP15 (SET UP)
D126 8-719-046-39 DIODE SEL5821A-TP15 (PHONO)
(DE535/SE491/V525)
D127 8-719-046-39 DIODE SEL5821A-TP15 (NAME)
D128 8-719-046-39 DIODE SEL5821A-TP15 (MD/TAPE)
D129 8-719-046-39 DIODE SEL5821A-TP15 (BASS/TREBLE)
D130 8-719-046-39 DIODE SEL5821A-TP15 (TU/LD)
D131 8-719-046-39 DIODE SEL5821A-TP15 (SUR)
D132 8-719-046-39 DIODE SEL5821A-TP15 (VIDEO)
D133 8-719-046-39 DIODE SEL5821A-TP15 (5.1CH/DVD)
< TRANSISTOR >
Q122 8-729-900-36 TRANSISTOR DTC124ES
Q124 8-729-900-36 TRANSISTOR DTC124ES
Q125 8-729-900-36 TRANSISTOR DTC124ES
Q126 8-729-900-36 TRANSISTOR DTC124ES (DE535/SE491/V525)
Q127 8-729-900-36 TRANSISTOR DTC124ES
Q128 8-729-900-36 TRANSISTOR DTC124ES
Q129 8-729-900-36 TRANSISTOR DTC124ES
Q130 8-729-900-36 TRANSISTOR DTC124ES
Q131 8-729-900-36 TRANSISTOR DTC124ES
Q132 8-729-900-36 TRANSISTOR DTC124ES
Q133 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R141 1-249-411-11 CARBON 330 5% 1/4W
R142 1-249-413-11 CARBON 470 5% 1/4W F
R143 1-249-415-11 CARBON 680 5% 1/4W F
R144 1-249-417-11 CARBON 1K 5% 1/4W F
R145 1-249-419-11 CARBON 1.5K 5% 1/4W F
R146 1-249-421-11 CARBON 2.2K 5% 1/4W F
R147 1-247-843-11 CARBON 3.3K 5% 1/4W
R148 1-249-425-11 CARBON 4.7K 5% 1/4W F
R149 1-249-429-11 CARBON 10K 5% 1/4W
R150 1-249-433-11 CARBON 22K 5% 1/4W
R154 1-249-415-11 CARBON 680 5% 1/4W F
R155 1-249-417-11 CARBON 1K 5% 1/4W F
R156 1-249-419-11 CARBON 1.5K 5% 1/4W F
R157 1-249-421-11 CARBON 2.2K 5% 1/4W F
R158 1-247-843-11 CARBON 3.3K 5% 1/4W
R159 1-249-425-11 CARBON 4.7K 5% 1/4W F
R160 1-249-429-11 CARBON 10K 5% 1/4W
R161 1-249-433-11 CARBON 22K 5% 1/4W
R162 1-249-413-11 CARBON 470 5% 1/4W F
R163 1-249-415-11 CARBON 680 5% 1/4W F
R164 1-249-417-11 CARBON 1K 5% 1/4W F
R165 1-249-419-11 CARBON 1.5K 5% 1/4W F
R166 1-249-421-11 CARBON 2.2K 5% 1/4W F
R167 1-247-843-11 CARBON 3.3K 5% 1/4W
R168 1-249-425-11 CARBON 4.7K 5% 1/4W F
R170 1-249-411-11 CARBON 330 5% 1/4W
R171 1-249-413-11 CARBON 470 5% 1/4W F
R172 1-249-415-11 CARBON 680 5% 1/4W F
R173 1-249-417-11 CARBON 1K 5% 1/4W F
R174 1-249-419-11 CARBON 1.5K 5% 1/4W F
R175 1-249-421-11 CARBON 2.2K 5% 1/4W F
R176 1-247-843-11 CARBON 3.3K 5% 1/4W
R177 1-249-425-11 CARBON 4.7K 5% 1/4W F
R178 1-249-429-11 CARBON 10K 5% 1/4W
R179 1-249-433-11 CARBON 22K 5% 1/4W
R180 1-249-437-11 CARBON 47K 5% 1/4W
R189 1-249-429-11 CARBON 10K 5% 1/4W
R190 1-249-437-11 CARBON 47K 5% 1/4W
R193 1-249-412-11 CARBON 390 5% 1/4W F
R194 1-249-412-11 CARBON 390 5% 1/4W F
R197 1-249-412-11 CARBON 390 5% 1/4W F
R198 1-249-412-11 CARBON 390 5% 1/4W F
< SWITCH >
S102 1-762-196-21 SWITCH, TACT (SOUND FIELD MODE –)
S103 1-762-196-21 SWITCH, TACT (FM/AM:DE435/V424)
(FM:DE535/SE491/V525)
S104 1-762-196-21 SWITCH, TACT (4)
S105 1-762-196-21 SWITCH, TACT (TUNING +)
S107 1-762-196-21 SWITCH, TACT (SOUND FIELED MODE +)
S108 1-762-196-21 SWITCH, TACT (FM MODE)
S109 1-762-196-21 SWITCH, TACT (5)
S110 1-762-196-21 SWITCH, TACT (TUNING –)
S112 1-762-196-21 SWITCH, TACT (SOUND FIELED ON/OFF)
S113 1-762-196-21 SWITCH, TACT (MEMORY)
INPUT KEY
