Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 49 —
IC803 8-759-604-46 IC M5F79M15
IC804 8-759-604-35 IC M5F78M05L
< JACK >
J201 1-770-614-11 JACK, PIN 4P (DE535/SE491/V525)
J202 1-691-887-11 JACK, PIN 6P (EXCEPT DE535/SE491/V525)
J202 1-770-613-11 JACK, PIN 4P (DE535/SE491/V525)
J203 1-580-825-11 JACK, PIN 6P
< TRANSISTOR >
L230 1-408-080-00 INDUCTOR 100uH (AEP,EE,CIS)
Q691 8-729-900-80 TRANSISTOR DTC114ES
Q692 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R201 1-249-401-11 CARBON 47 5% 1/4W F
(DE535/SE491/V525)
R202 1-249-441-11 CARBON 100K 5% 1/4W
(DE535/SE491/V525)
R203 1-249-440-11 CARBON 82K 5% 1/4W
(DE535/SE491/V525)
R204 1-249-408-11 CARBON 180 5% 1/4W F
(DE535/SE491/V525)
R205 1-249-428-11 CARBON 8.2K 5% 1/4W F
(DE535/SE491/V525)
R206 1-249-441-11 CARBON 100K 5% 1/4W
(DE535/SE491/V525)
R207 1-247-807-31 CARBON 100 5% 1/4W
(DE535/SE491/V525)
R208 1-249-441-11 CARBON 100K 5% 1/4W
(DE535/SE491/V525)
R209 1-249-413-11 CARBON 470 5% 1/4W F
(DE535/SE491/V525)
R210 1-249-417-11 CARBON 1K 5% 1/4W F
R211 1-249-417-11 CARBON 1K 5% 1/4W F
R212 1-249-417-11 CARBON 1K 5% 1/4W F
R213 1-249-417-11 CARBON 1K 5% 1/4W F
R214 1-249-417-11 CARBON 1K 5% 1/4W F
R215 1-249-417-11 CARBON 1K 5% 1/4W F
R216 1-249-441-11 CARBON 100K 5% 1/4W
R217 1-249-429-11 CARBON 10K 5% 1/4W
R218 1-249-434-11 CARBON 27K 5% 1/4W
R227 1-249-429-11 CARBON 10K 5% 1/4W
R228 1-247-807-31 CARBON 100 5% 1/4W
R229 1-247-807-31 CARBON 100 5% 1/4W
R230 1-249-425-11 CARBON 4.7K 5% 1/4W F
R231 1-249-436-11 CARBON 39K 5% 1/4W
R232 1-247-807-31 CARBON 100 5% 1/4W
(AEP,EE,CIS)
R233 1-247-807-31 CARBON 100 5% 1/4W
(AEP,EE,CIS)
R234 1-249-421-11 CARBON 2.2K 5% 1/4W F
(AEP,EE,CIS)
R235 1-249-436-11 CARBON 39K 5% 1/4W
R245 1-249-429-11 CARBON 10K 5% 1/4W
R251 1-249-401-11 CARBON 47 5% 1/4W F
(DE535/SE491/V525)
R252 1-249-441-11 CARBON 100K 5% 1/4W
(DE535/SE491/V525)
R253 1-249-440-11 CARBON 82K 5% 1/4W
(DE535/SE491/V525)
R254 1-249-408-11 CARBON 180 5% 1/4W F
(DE535/SE491/V525)
R255 1-249-428-11 CARBON 8.2K 5% 1/4W F
(DE535/SE491/V525)
R256 1-249-441-11 CARBON 100K 5% 1/4W
(DE535/SE491/V525)
R257 1-247-807-31 CARBON 100 5% 1/4W
(DE535/SE491/V525)
R258 1-249-441-11 CARBON 100K 5% 1/4W
(DE535/SE491/V525)
R259 1-249-413-11 CARBON 470 5% 1/4W F
(DE535/SE491/V525)
R260 1-249-417-11 CARBON 1K 5% 1/4W F
R261 1-249-417-11 CARBON 1K 5% 1/4W F
R262 1-249-417-11 CARBON 1K 5% 1/4W F
R263 1-249-417-11 CARBON 1K 5% 1/4W F
R264 1-249-417-11 CARBON 1K 5% 1/4W F
R265 1-249-417-11 CARBON 1K 5% 1/4W F
R266 1-249-441-11 CARBON 100K 5% 1/4W
R267 1-249-429-11 CARBON 10K 5% 1/4W
R268 1-249-434-11 CARBON 27K 5% 1/4W
R277 1-249-429-11 CARBON 10K 5% 1/4W
R295 1-249-429-11 CARBON 10K 5% 1/4W
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-439-11 CARBON 68K 5% 1/4W
R503 1-249-439-11 CARBON 68K 5% 1/4W
R504 1-249-420-11 CARBON 1.8K 5% 1/4W F
(AEP,EE,CIS)
R504 1-249-418-11 CARBON 1.2K 5% 1/4W F
(EXCEPT AEP,EE,CIS)
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-439-11 CARBON 68K 5% 1/4W
R553 1-249-439-11 CARBON 68K 5% 1/4W
R554 1-249-420-11 CARBON 1.8K 5% 1/4W F
(AEP,EE,CIS)
R554 1-249-418-11 CARBON 1.2K 5% 1/4W F
(EXCEPT AEP,EE,CIS)
R590 1-249-433-11 CARBON 22K 5% 1/4W
R592 1-249-381-11 CARBON 1 5% 1/4W F
R593 1-249-381-11 CARBON 1 5% 1/4W F
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-249-439-11 CARBON 68K 5% 1/4W
R604 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT AEP,EE,CIS)
R604 1-249-442-11 CARBON 510 5% 1/4W
(AEP,EE,CIS)
R606 1-249-413-11 CARBON 470 5% 1/4W F
R693 1-249-437-11 CARBON 47K 5% 1/4W
R694 1-249-425-11 CARBON 4.7K 5% 1/4W F
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-439-11 CARBON 68K 5% 1/4W
R704 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT AEP,EE,CIS)
R704 1-249-442-11 CARBON 510 5% 1/4W
(AEP,EE,CIS)
R751 1-249-417-11 CARBON 1K 5% 1/4W F
