NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 44 —
SECTION 5
ELECTRICAL PARTS LIST
• Abbreviation
CND : Canadian
AUS : Australian
CH : Chinese
MY : Malaysia
SP : Singapore
EA : Saudi Arabia
EE : East European
1-673-002-11 BALANCE BOARD
**************
< CONNECTOR >
* CNS106 1-695-808-11 CONNECTOR, PC BOARD 8P
CNS401 1-770-398-11 HOUSING, CONNECTOR (PC BOARD) 5P
< DIODE >
D122 8-719-046-39 DIODE SEL5821A-TP15 (MUTING)
< TRANSISTOR >
Q122 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R152 1-249-411-11 CARBON 330 5% 1/4W
R153 1-249-413-11 CARBON 470 5% 1/4W F
R185 1-249-412-11 CARBON 390 5% 1/4W F
R186 1-249-412-11 CARBON 390 5% 1/4W F
< VARIABLE RESISTOR >
RV402 1-225-447-11 RES, VAR, CARBON 100K/100K (BALANCE)
< SWITCH >
S106 1-762-196-21 SWITCH, TACT (TONE)
S111 1-762-196-21 SWITCH, TACT (BASS BOOST)
S116 1-762-196-21 SWITCH, TACT (MUTING)
************************************************************
1-672-991-11 BRIDGE-A BOARD
**************
< CONNECTOR >
CNP652 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNP654 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
************************************************************
1-672-992-11 BRIDGE-B BOARD
**************
< CONNECTOR >
CNP651 1-785-820-11 CONNECTOR, BOARD TO BOARD 15P
CNP653 1-785-820-11 CONNECTOR, BOARD TO BOARD 15P
************************************************************
A-4419-073-A DISPLAY BOARD, COMPLETE (DE535:US,CND)
************************
A-4419-201-A DISPLAY BOARD, COMPLETE (SE491)
************************
A-4419-206-A DISPLAY BOARD, COMPLETE (DE535:AUS)
************************
A-4419-210-A DISPLAY BOARD, COMPLETE (DE535;MY,SP)
************************
A-4419-213-A DISPLAY BOARD, COMPLETE (DE535;E)
************************
A-4419-217-A DISPLAY BOARD, COMPLETE (DE435;US,CND)
************************
A-4419-223-A DISPLAY BOARD, COMPLETE (DE435:AUS)
************************
A-4419-225-A DISPLAY BOARD, COMPLETE
************************
(DE435:MY,SP/V424)
A-4419-228-A DISPLAY BOARD, COMPLETE (AEP)
************************
A-4419-236-A DISPLAY BOARD, COMPLETE (EE,CIS)
************************
* A-4419-605-A DISPLAY BOARD, COMPLETE (V525)
************************
* 3-386-245-11 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C101 1-164-159-11 CERAMIC 0.1uF 50V
C102 1-164-159-11 CERAMIC 0.1uF 50V
C103 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-124-465-00 ELECT 0.47uF 20% 50V
C105 1-164-159-11 CERAMIC 0.1uF 50V
C106 1-126-163-11 ELECT 4.7uF 20% 50V
C107 1-124-261-00 ELECT 10uF 20% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-124-589-11 ELECT 47uF 20% 16V
C111 1-124-589-11 ELECT 47uF 20% 16V
(EXCEPT DE535:US,CND)
BALANCE BRIDGE-A
BRIDGE-B DISPLAY
