Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 52 —
* CNP801 1-564-243-11 PIN, CONNECTOR 6P
* CNP802 1-564-506-11 PLUG, CONNECTOR 3P
CNS102 1-569-932-11 SOCKET, CONNECTOR 15P
CNS602 1-569-928-11 SOCKET, CONNECTOR 11P
CNS651 1-785-819-11 HOUSING, CONNECTOR(PC BOARD) 15P
CNS652 1-770-404-11 HOUSING, CONNECTOR(PC BOARD) 11P
< DIODE >
D501 8-719-911-19 DIODE 1SS119
D502 8-719-109-54 DIODE RD2.2ES-B2
D503 8-719-109-54 DIODE RD2.2ES-B2
D504 8-719-911-19 DIODE 1SS119
D505 8-719-911-19 DIODE 1SS119
D506 8-719-911-19 DIODE 1SS119
D513 8-719-911-19 DIODE 1SS119
D546 8-719-911-19 DIODE 1SS119
D551 8-719-911-19 DIODE 1SS119
D552 8-719-109-54 DIODE RD2.2ES-B2
D553 8-719-109-54 DIODE RD2.2ES-B2
D554 8-719-911-19 DIODE 1SS119
D555 8-719-911-19 DIODE 1SS119
D556 8-719-911-19 DIODE 1SS119
D596 8-719-911-19 DIODE 1SS119
D601 8-719-911-19 DIODE 1SS119
D602 8-719-109-54 DIODE RD2.2ES-B2
D603 8-719-109-54 DIODE RD2.2ES-B2
D604 8-719-911-19 DIODE 1SS119
D651 8-719-911-19 DIODE 1SS119
D652 8-719-911-19 DIODE 1SS119
D653 8-719-911-19 DIODE 1SS119
D660 8-719-911-19 DIODE 1SS119
D661 8-719-911-19 DIODE 1SS119
D801 8-719-302-38 DIODE RBV-602-01
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-024-99 DIODE 11ES2-NTA2B
D805 8-719-024-99 DIODE 11ES2-NTA2B
D806 8-719-160-26 DIODE RD5.6F-B2 (EXCEPT CND/SE491)
D806 8-719-069-68 DIODE RD5.6F-T7 (CND/SE491)
D807 8-719-934-17 DIODE HZS27-1L
D809 8-719-210-21 DIODE 11EQS04
< FUSE >
! F801 1-532-311-11 FUSE GLASS TUBE 8.0A 125V
(MY,SP,AUS,E,CH)
! F801 1-533-506-51 FUSE TL6.3A 250V(AEP,EE,CIS)
! F802 1-532-506-51 FUSE TL6.3A 250V(AEP,EE,CIS)
! F802 1-533-311-11 FUSE GLASS TUBE 8.0A 125V
(MY,SP,AUS,E,CH)
< IC >
IC809 8-759-708-05 IC NJM78L05A
IC950 8-759-231-53 IC TA7805S
< COIL >
L501 1-420-872-00 COIL, AIR-CORE
L551 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q504 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q505 8-729-209-15 TRANSISTOR 2SD2012
Q506 8-749-010-25 IC MN2488-OPY-M
Q507 8-749-010-26 IC MP1620-OPY-M
Q508 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q509 8-729-281-53 TRANSISTOR 2SC1815-GR
Q510 8-729-900-63 TRANSISTOR DTA124ES
Q511 8-729-900-63 TRANSISTOR DTA124ES
Q513 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q546 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q554 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q555 8-729-209-15 TRANSISTOR 2SD2012
Q556 8-749-010-25 IC MN2488-OPY-M
Q557 8-749-010-26 IC MP1620-OPY-M
Q558 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q559 8-729-281-53 TRANSISTOR 2SC1815-GR
Q560 8-729-900-63 TRANSISTOR DTA124ES
Q561 8-729-900-63 TRANSISTOR DTA124ES
Q596 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-209-15 TRANSISTOR 2SD2012
Q606 8-749-010-25 IC MN2488-OPY-M
Q607 8-749-010-26 IC MP1620-OPY-M
Q608 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q651 8-729-281-53 TRANSISTOR 2SC1815-GR
Q652 8-729-900-36 TRANSISTOR DTC124ES
Q653 8-729-281-53 TRANSISTOR 2SC1815-GR
Q654 8-729-900-36 TRANSISTOR DTC124ES
Q655 8-729-201-53 TRANSISTOR 2SA1015-GR
Q656 8-729-900-63 TRANSISTOR DTA124ES
Q657 8-729-900-36 TRANSISTOR DTC124ES
Q660 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q661 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q662 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q801 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R507 1-249-431-11 CARBON 15K 5% 1/4W
R510 1-215-868-00 METAL OXIDE 680 5% 1W F
R511 1-249-425-11 CARBON 4.7K 5% 1/4W F
R512 1-249-429-11 CARBON 10K 5% 1/4W
R518 1-249-435-11 CARBON 33K 5% 1/4W
(AEP,EE,CIS)
R518 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT AEP,EE,CIS)
R519 1-249-435-11 CARBON 33K 5% 1/4W
(AEP,EE,CIS)
R519 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT AEP,EE,CIS)
R521 1-249-429-11 CARBON 10K 5% 1/4W
R523 1-249-421-11 CARBON 2.2K 5% 1/4W F
R524 1-249-408-11 CARBON 180 5% 1/4W F
R525 1-249-408-11 CARBON 180 5% 1/4W F
R526 1-234-182-11 ENCAPSULATED COMPONENT
R527 1-249-427-11 CARBON 6.8K 5% 1/4W F
R528 1-249-419-11 CARBON 1.5K 5% 1/4W F
P. AMP
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
