Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 59 —
A-4419-075-A VOL BOARD, COMPLETE
********************
< CAPACITOR >
C090 1-126-960-11 ELECT 1uF 20% 50V
C091 1-126-960-11 ELECT 1uF 20% 50V
< CONNECTOR >
CNP105 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNP401 1-770-389-11 PIN, CONNECTOR (PC BOARD) 5P
CNS402 1-569-904-11 SOCKET, CONNECTOR 9P
CNS404 1-569-906-11 SOCKET, CONNECTOR 11P
< VARIABLE RESISTOR >
RV401 1-225-776-11 RES, VAR, CARBON 100K/100K × 5
(MASTER VOLUME)
************************************************************
1-672-996-11 VOLTAGE SELECTOR BOARD (DE535:E)
***********************
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
* CNP906 1-566-664-11 PIN, CONNECTOR 4P
< SWITCH >
! S901 1-571-437-11 SWITCH POWER VOLTAGE CHANGE
************************************************************
MISCELLANEOUS
**************
27 1-769-991-11 WIRE (FLAT TYPE) (13 CORE)
(DE435,SE491,V424)
27 1-773-024-11 WIRE (FLAT TYPE) (15 CORE)(DE535/V525)
28 1-773-012-11 WIRE (FLAT TYPE) (15 CORE)
62 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
! 65 1-696-847-11 CORD, POWER (DE435:AUS/DE535:AUS)
! 65 1-777-070-21 CORD, POWER (DE435:CND/DE535:CND)
! 65 1-777-071-21 CORD, POWER
(DE435:AEP,EE,CIS,MY,SP/DE535:E,MY,SP)
! 65 1-783-205-11 CORD, POWER (V424/V525)
! 65 1-783-820-11 CORD, POWER (DE435:US/DE535:US/SE491)
69 1-773-008-11 WIRE (FLAT TYPE) (15 CORE)
70 1-769-942-11 WIRE (FLAT TYPE) (11 CORE)
71 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
73 1-693-407-62 TUNER
(DE435:US,CND/DE535:US,CND,E/SE491)
73 1-693-408-41 TUNER
(DE435:AEP,MY,SP,AUS/DE535:MY,SP,AUS/V424/V525)
73 1-693-411-43 TUNER (DE435:EE,CIS)
74 1-773-004-11 WIRE (FLAT TYPE) (15 CORE)
! 78 1-569-008-21 ADAPTOR, CONVERSION 2P (DE535: E)
Q705 8-729-209-15 TRANSISTOR 2SD2012
Q706 8-749-010-25 IC MN2488-OPY-M
Q707 8-749-010-26 IC MP1620-OPY-M
Q755 8-729-209-15 TRANSISTOR 2SD2012
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
! T901 1-433-679-11 TRANSFORMER, POWER
(DE435:CND/DE535:CND)
! T901 1-433-680-11 TRANSFORMER, POWER
(DE435:US/DE535:US)
! T901 1-433-680-21 TRANSFORMER, POWER (SE491)
! T901 1-433-681-11 TRANSFORMER, POWER (DE435:AEP,EE,CIS)
! T901 1-433-682-11 TRANSFORMER, POWER
(DE435:AUS/DE535:AUS)
! T901 1-433-683-11 TRANSFORMER, POWER
(DE435:MY,SP/DE535:MY,SP/V424/V525)
! T901 1-433-684-11 TRANSFORMER, POWER (DE535:E)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-418-293-11 REMOTE COMMANDER (RM-LJ302)
(DE535/V525)
1-501-374-11 ANTENNA LOOP
1-501-594-11 ANTENNA (FM) (EXCEPT US,CND)
3-866-247-11 MANUAL,INSTRUCTION (ENGLISH) (US)
3-866-247-21 MANUAL,INSTRUCTION (FRENCH)
(CND,MY,SP,E,AUS)
3-866-247-31 MANUAL,INSTRUCTION (ENGLISH,CHINESE)
(CH)
3-866-247-41 MANUAL,INSTRUCTION
(SWEDISH,SPANISH,ITALIAN,PORTUGUESE) (AEP)
3-866-247-51 MANUAL,INSTRUCTION
(ENGLISH,FRENCH,DUTCH,GERMAN) (AEP)
3-866-247-61 MANUAL,INSTRUCTION
(ENGLISH,RUSSIAN,POLISH) (EE,CIS)
3-866-295-11 MANUAL,INSTRUCTION (RM-LJ302)(ENGLISH)
(DE535/V525)
3-866-295-21 MANUAL,INSTRUCTION(RM-LJ302)
(FRENCH,SPANISH) (DE535:CND,E)
3-866-295-31 MANUAL,INSTRUCTION (RM-LJ302)(CHINESE)
(DE535:MY,SP/V525)
3-866-296-11 MANUAL,INSTRUCTION (RM-PP402)
(ENGLISH) (DE435/SE491/V424)
3-866-296-21 MANUAL,INSTRUCTION (RM-PP402)
(FRENCH,SPANISH) (DE435:CND/AEP)
3-866-296-31 MANUAL,INSTRUCTION (RM-PP402)(CHINESE)
(DE435:MY,SP/V424)
3-866-296-41 MANUAL,INSTRUCTION (RM-PP402)
(DUTCH,SWEDISH,GERMAN,ITALIAN,PORTUGUESE) (DE435:AEP)
3-866-296-51 MANUAL,INSTRUCTION (RM-PP402)
(DANISH,FINNISH) (DE435:AEP)
3-866-296-61 MANUAL,INSTRUCTION (RM-PP402)
(POLISH,RUSSIAN) (DE435:EE,CIS)
3-866-296-71 MANUAL,INSTRUCTION (RM-PP402) (CZECH)
(DE435:EE,CIS)
3-866-419-11 MANUAL (RECV.HOOK-UP)(EXCEPT SE491)
3-866-670-11 MANUAL,COMMONNESS INSTRUCTION
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
