STR-DE598/DE698/DV10
Models of area code AEP, UK, E2, AUS, AR, KR, TW
Rated Power Output at Stereo Mode
(8 ohms 20 Hz – 20 kHz, THD 0.09 %)
80 W + 80 W
1)
(EXCEPT AEP, UK)
90 W + 90 W
1)
(AEP, UK)
70 W + 70 W
3)
(8 ohms 1 kHz, THD 0.7 %)
100 W + 100 W
1)
90 W + 90 W
3)
(8 ohms 1 kHz, THD 10 %)
120 W + 120 W
1)
(EXCEPT AEP, UK)
125 W + 125 W
1)
(AEP, UK)
110 W + 110 W
3)
Reference Power Output
1)
(8 ohms 20 Hz – 20 kHz, THD 0.09 %)
FRONT
2)
: 110 W/ch
CENTER
2)
: 110 W
SURR
2)
: 110 W/ch
SURR BACK
2)
:
110 W (DE598)
110 W/ch (DE698)
(8 ohms 1 kHz, THD 0.7 %)
FRONT
2)
: 120 W/ch
CENTER
2)
: 120 W
SURR
2)
: 120 W/ch
SURR BACK
2)
:
120 W (DE598)
120 W/ch (DE698)
(8 ohms 1 kHz, THD 10 %)
FRONT
2)
: 150 W/ch
CENTER
2)
: 150 W
SURR
2)
: 150 W/ch
SURR BACK
2)
:
150 W (DE598)
150 W/ch (DE698)
1) Measured under the following conditions:
Area code Power requirements
US, CND 120 V AC, 60 Hz
AEP, UK, AR, KR 230 V AC, 50 Hz
E2, AUS 240 V AC, 50 Hz
TW 110 V AC, 60 Hz
2) Depending on the sound field settings and the
source, there may be no sound output.
3) Measured under the following conditions:
Area code Power requirements
AR, KR 220 V AC, 50 Hz
Frequency response
MULTI CH IN, SA-CD/ 10 Hz – 70 kHz
CD, MD/TAPE, DVD, +0.5/–2 dB (with sound
AUX (DE698/DV10), field and tone (DE598) or
VIDEO 1, 2, 3 equalizer (DE698/DV10)
bypassed)
Inputs (Analog)
MULTI CH IN, SA-CD/ Sensitivity: 500 mV
CD, MD/TAPE, DVD, Impedance: 50 k ohms
AUX (DE698/DV10), S/N
4)
: 96 dB
VIDEO 1, 2, 3 (A, 500 mV
5)
)
4) INPUT SHORT (with sound field and tone (DE598) or
equalizer (DE698/DV10) bypassed).
5) Weighted network, input level.
Inputs (Digital)
DVD, Sensitivity: –
SA-CD/CD (DE698/ Impedance: 75 ohms
DV10) (Coaxial) S/N: 100 dB
(A, 20 kHz LPF)
VIDEO 2, Sensitivity: –
3, MD/TAPE (DE698/ Impedance: –
DV10), S/N: 100 dB
SA-CD/CD (Optical) (A, 20 kHz LPF)
Outputs (Analog)
MD/TAPE (OUT), Voltage: 500 mV
VIDEO 1 (AUDIO OUT) Impedance: 10 k ohms
SUB WOOFER Voltage: 2 V
Impedance: 1 k ohms
Outputs (Digital) (DE698/DV10)
MD/TAPE (Optical) Sensitivity: –
Tone (DE598),
Equalizer (DE698/DV10)
Gain levels ±6 dB, 1 dB step
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Useable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code US, CND
With 10-kHz tuning scale: 530 – 1,710 kHz
6)
With 9-kHz tuning scale: 531 – 1,710 kHz
6)
Models of area code E2
With 10-kHz tuning scale: 530 – 1,610 kHz
6)
With 9-kHz tuning scale: 531 – 1,602 kHz
6)
Models of area code AEP, UK, AUS, TW, KR
With 9-kHz tuning scale: 531 – 1,602 kHz
Models of area code AR
With 10-kHz tuning scale: 530 – 1,610 kHz
Antenna Loop antenna
Intermediate frequency 450 kHz
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
6) You can change the AM tuning scale to 9 kHz or 10 kHz.
After tuning in any AM station, turn off the receiver. While
holding down PRESET TUNING + or TUNING +, press
?/1. All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9 kHz),
repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
(DE698/DV10) C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO:
(Except for models of area code DE598: AEP, UK)
Y: 1 Vp-p, 75 ohms
PB/CB/B-Y: 0.7 Vp-p,
75 ohms
PR/CR/R-Y: 0.7 Vp-p,
75 ohms
80 MHz HD Pass Through
Ver. 1.1
