50
STR-DE598/DE698/DV10
Ver. 1.1
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SELECT BOARD (E2)
****************
< CONNECTOR >
* CNP910 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< SWITCH >
0S901 1-571-437-21 SWITCH, POWER VOLTAGE
(VOLTAGE SELECTOR)
*************************************************************
A-1084-347-A DIGITAL BOARD, COMPLETE (DE598:US,CND)
A-1084-409-A DIGITAL BOARD, COMPLETE (DE598:AEP,UK)
A-1084-603-A DIGITAL BOARD, COMPLETE (DE598:AUS)
A-1084-706-A DIGITAL BOARD, COMPLETE (DE598:KR,TW)
A-1084-981-A DIGITAL BOARD, COMPLETE (DE598:E2)
A-1084-989-A DIGITAL BOARD, COMPLETE (DE598:AR)
A-1084-997-A DIGITAL BOARD, COMPLETE (DE698:US,CND)
A-1085-103-A DIGITAL BOARD, COMPLETE (DE698:AEP,UK)
A-1085-213-A DIGITAL BOARD, COMPLETE (DE698:AUS)
A-1085-252-A DIGITAL BOARD, COMPLETE (DE698:E2)
A-1089-520-A DIGITAL BOARD, COMPLETE (DV10)
A-1091-920-A DIGITAL BOARD, COMPLETE (DE698:AR)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-126-925-11 ELECT 470uF 20% 10V
C1002 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1004 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1021 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-126-925-11 ELECT 470uF 20% 10V
C1031 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1032 1-126-925-11 ELECT 470uF 20% 10V
C1045 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
(DE698/DV10)
C1046 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
(DE698/DV10)
C1047 1-104-662-11 ELECT 22uF 20% 25V
(DE698/DV10)
C1063 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
(AEP,UK)
C1064 1-126-947-11 ELECT 47uF 20% 35V
(AEP,UK)
C1100 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1102 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1103 1-126-947-11 ELECT 47uF 20% 35V
C1107 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1108 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1118 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1119 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1120 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1121 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1122 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1123 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1124 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1125 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DE698/DV10)
C1126 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1128 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
(DE698/DV10)
C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1131 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(DE698/DV10)
C1132 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(DE698/DV10)
C1137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1138 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1139 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1140 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1141 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
(DE698/DV10)
C1142 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1149 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1251 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1252 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1253 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1254 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1255 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1299 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1301 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1302 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1303 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1304 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1305 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1306 1-126-947-11 ELECT 47uF 20% 35V
C1308 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1309 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1310 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
•Abbreviation
CND : Canadian model
E2 : AC 120 V area in E model
AUS: Australian model
AR : Argentina model
KR : Korean model
TW : Taiwan model
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
